Key Features
-
Pro performance. Process data with a 1.25GHz PowerPC G4 processor, dedicated L3 cache, and up to 2GB of DDR SDRAM memory.
-
Xserve-based architecture. Move data efficiently and accelerate application performance with this low-latency system architecture.
-
Massive expansion. Add all the capabilities you need using the PCI and DDR SDRAM slots, hard drive bays, optical drive bays, and FireWire, USB, and audio connections.
Leading graphics and displays. Process up to 136 million triangles per second for compelling 3D design, visualization, and gaming. Attach a second Apple display for even more workspace.(1)
-
Mac OS X. Take advantage of the power and stability of UNIX combined with the ease of use of the Mac.
| Configurations |
|
| Order no. |
M9145LL/A |
| Processor |
1.25GHz PowerPC G4 |
| L3 cache |
1MB DDR SRAM |
| System bus |
167MHz |
| Memory |
256MB PC2700 (333MHz) DDR SDRAM; 2GB maximum(2) |
| Hard disk drive |
80GB Ultra ATA/100; 7200 rpm(3) |
| Optical drive |
Combo (DVD-ROM/CD-RW) |
| Graphics support |
ATI Radeon 9000 Pro with 64MB DDR SDRAM and full dual display support |
| Expansion slots and bays |
Four open full-length 64-bit, 33MHz PCI slots; AGP 4X slot with graphics card installed; four DIMM slots; four internal hard drive bays (one occupied); two optical drive bays (one occupied) |
| Ports |
Two FireWire 400, four USB ports (two on system, two on keyboard), front headphone minijack and speaker, rear Apple speaker minijack, analog audio line in and analog audio line out minijacks, ADC and DVI connectors for dual display support
|
| Networking |
Built-in 10/100/1000BASE-T Ethernet, AirPort ready(4), v.92 56K modem (5) |
| System software |
Mac OS X v10.2 “Jaguar”, Mac OS 9 |
| Software |
Mail, iChat, Safari, Sherlock, Address Book, QuickTime, iLife (includes iTunes, iPhoto, iMovie and iDVD), iSync, iCal, DVD Player, Classic environment, Acrobat Reader, Art Directors Toolkit, EarthLink, FAXstf, FileMaker Pro Trial, GraphicConverter, Microsoft Office v. X Test Drive, OmniGraffle, OmniOutliner, QuickBooks for Mac New User Edition, and Developer Tools |
| Hardware accessories |
Apple Pro Keyboard, Apple Pro Mouse, USB keyboard extension cable, DVI to VGA adapter, modem cable |
| Limited warranty and service |
Your Power Mac G4 comes with 90 days of telephone support and a one-year limited warranty. Purchase the AppleCare Protection Plan to extend your service and support to three full years. Only the AppleCare Protection Plan provides you with direct telephone support from Apple technical experts and the assurance that repairs will be handled by Apple-certified technicians using genuine Apple parts. For more information, visit Apple support or call 800-823-2775. |
| Internet access |
All models also include 30 days of free Internet service through EarthLink. Internet access requires a compatible Internet service provider; fees may apply.
|
| Service and support |
90 days of free telephone support and one-year limited warranty |
| |
|
| Build-to-Order Options |
| Processors |
Dual 1.25GHz PowerPC G4 processors (with 2 MB DDR SRAM L3 cache per processor)
|
| Memory |
256MB, 512MB, 1GB, 1.5GB, 2GB (PC2700 DDR SDRAM)
|
| Hard drives (7200 rpm) |
80GB Ultra ATA/100 (7200 rpm), 160GB Ultra ATA/100 (7200 rpm) |
| Optical drives |
SuperDrive (DVD-R/CD-RW), Combo drive (DVD-ROM/CD-RW) |
| Graphics |
ATI Radeon 9000 Pro with 64MB DDR SDRAM, NVIDIA GeForce4 Titanium with 128MB DDR SDRAM |
| Audio |
Apple Pro Speakers, Apple iPod, Harman Kardon SoundSticks |
| Wireless |
AirPort Card M7600LL/E
AirPort Extreme Base Station M8930LL/A
AirPort Extreme Base Station (with modem and antenna port) M8799LL/A |
| Displays |
Apple Studio Display (17-inch flat panel) M7649ZM/B
Apple Cinema Display (20-inch flat panel) M8893ZM/A
Apple Cinema HD Display (23-inch flat panel) M8537ZM/A
Apple DVI to ADC Display Adapter M8661LL/A |
| Services |
AppleCare Protection Plan M8850LL/A
.Mac Subscription M8778LL/A |
| Technical Specifications |
Processing and memory
- 1.25GHz PowerPC G4 processor
- Dual 1.25GHz PowerPC G4 processors (build-to-order option)
- Velocity Engine for 128-bit single-instruction, multiple data (SIMD) processing
- Full 128-bit internal memory data paths
- Powerful floating-point unit supporting single-cycle, double-precision calculations
- Data stream prefetching operations supporting four simultaneous 32-bit data streams
- 256K on-chip L2 cache running at processor speed
- 1MB DDR SRAM L3 cache per processor (2MB DDR SRAM L3 cache per processor with dual 1.25GHz PowerPC G4 build-to-order option)
- 167MHz system bus supporting over 1.3GBps data throughput
- 256MB of PC2700 (333MHz) DDR SDRAM main memory supporting up to 2.7GBps throughput
- Four DIMM slots supporting up to 2GB of DDR SDRAM using one of the following (2):
- 256MB DIMMs (64-bit-wide, 128 or 256 Mbit)
- 512MB DIMMs (64-bit-wide, 256 Mbit
Graphics and display support
- ATI Radeon 9000 Pro graphics card with 64MB of DDR SDRAM preinstalled in a dedicated AGP 4X graphics slot
- NVIDIA GeForce4 Titanium graphics card with 128MB of DDR SDRAM (build-to-order option)
- Support for digital resolutions up to 1920 by 1200 pixels; analog resolutions up to 1600 by 1200 pixels
- ADC and DVI connectors; DVI to VGA adapter included
- Dual display support for extended desktop and video mirroring modes
- Support for up to two Apple flat-panel displays (1)
|
Communications
- 10/100/1000BASE-T Ethernet connector (RJ-45)
- Built-in antennas and expansion slot for optional 11-Mbps AirPort Card (based on 802.11b Wi-Fi certified) (4)
- Built-in 56K v.92 modem (5)
Storage and expansion
- Four 3.5-inch hard drive expansion bays:
- One 80GB 7200-rpm Ultra ATA/100 drive preinstalled (160GB build-to-order option)(3)
- Support for up to four internal ATA drives (two Ultra ATA/100 and two Ultra ATA/66)
- Support for up to four internal SCSI drives (requires third-party solution not offered by Apple
- Support for a combination of internal SCSI and ATA drives (total of four, requires third-party solution not offered by Apple)
- Two optical drive bays:
- Combo drive (DVD-ROM/CD-RW) preinstalled; reads DVDs at 12x speed, writes CD-R discs at 32x speed, writes CD-RW discs at 10x speed, reads CDs at 32x speed
- SuperDrive (DVD-R/CD-RW); writes DVD-R discs at 4x speed, reads DVDs at 8x speed, writes CD-R discs at 16x speed, writes CD-RW discs at 8x speed, reads CDs at 32x speed (build-to-order option)
- Optional Combo drive in second optical drive bay
- Four open, full-length 64-bit, 33MHz PCI slots
|
Peripherals and audio
- Two FireWire 400 ports (15W total power)
- Four USB ports (two on system, two on keyboard)
- Front headphone jack and speaker
- Stereo analog audio line in and line out minijacks
- Apple speaker minijack for connection to optional Apple Pro Speakers
Electrical and environmental requirements
- Meets ENERGY STAR requirements
- Line voltage: 100-120V AC or 200V-240V AC
- Frequency: 50Hz to 60Hz, single phase
- Maximum current: 6.5A (low voltage range) or 3.5A (high voltage range)
- Operating temperature: 50° to 95° F (10° to 35° C)
- Storage temperature: -40° to 116° F (-40° to 47° C)
- Relative humidity: 5% to 95% noncondensing
- Maximum altitude: 10,000 feet
Size and weight
- Height: 17.0 inches (43.2 cm)
- Width: 8.9 inches (22.7 cm)
- Depth: 18.4 inches (46.8 cm)
- Weight: 42 pounds (19.1 kg) (7)
|
(1) Second Apple flat-panel display requires Apple DVI to ADC Adapter, sold separately.
(2) 999MB maximum per application in the Mac OS X Classic environment.
(3) 1GB = 1 billion bytes; actual formatted capacity less.
(4) Wireless Internet access requires AirPort Card, AirPort Extreme Base Station or AirPort Base Station, and Internet access (fees may apply). Some ISPs are not currently compatible with AirPort and AirPort Extreme. Range may vary with site conditions.
(5) Compatible ISP and telephone services required. Your ISP may not support all V.92 features. Modem will function according to V.90 standards if V.92 services are not available. Actual modem speeds lower.
(6) Weight varies by configuration and manufacturing process.
(7) SuperDrive required for iDVD.
Product contains electronic documentation. Backup copy of software is included.
