(*) AL Tech MediaGate MG-350HD Video/Audio/Photo player W/ 3.5" Hard Drive Bay (no drive included), wired or wireless network connectivity. BRAND NEW, 1 year AL Tech warranty. *While our supply lasts!* (ATCMG350HD)
|
Same Day
|
$179.00 |
| Supply Limited: 3 available |
 |
 |
|
Main Features
- It is a highly-performed player, DMA with 3.5-inch HDD.
- It has a 11g wireless connection
- Time-sliced dual-band 11a/g is possible upon request. One 10/100 Ethernet port is provided.
- The player has a built-in 3.5-inch HDD
- As the price of 3.5-inch HDD is the lowest compared to other sizes, users can easily install 80G or 120G for storing digital movies
- Has a USB2.0 slave port. It provides an alternative way to download digital contents from the PC
- Also has a USB2.0 host port. Thus USB storage devices can be attached and the stored content can be played directly
- Supports MPEG-2, MPEG-4, ISMA MPEG-4, MPEG4 and WMV9 over MPEG-2 transport and WMV9 streaming. The 3.5-inch HDD is optional
- In this case, the player can be a low-cost DMA without HDD
- Can be configured with
- Web-based movie distributor as a media gateway to access, play and/or legally download movies from the web
- Download does not need a home PC
- Optimal OEM/ODM solution in high-performance DMA
- The DMA is designed to be flexible and easily fits the customer's requirements
Other Features
- Has one 10/100 LAN port
- Supports USB2.0 host/slave
- 3.5-inch HDD is user-installable
- Supports HD MP2, MP4 and WMV9
- Supports MP1/2@HL (720p/1,080i), MP4@L5 (720p) and WMV9 MP@ML (720p)
- Supports composite, S-video, component video outputs
- Supports stereo L/R, optical/coaxial digital audio, analog 5.1 channels
- Supports JPEG/BMP/GIF/PNG still picture
- File-surfing from multiple sources on TV using a remote controller
- PCs in the network
- HDD inside
- USB devices attached
|
|
General
| Product Name |
MEDIAGATE MG-350HD |
| Network |
IEEE802.3 (Ethernet) |
| Antenna |
2.5 dBi |
| Power |
DC 5V, 12V |
| Weight |
250g (Without a HDD) |
| Dimension |
57 x 150 x 185 mm |
| Working Temperature |
0° - 50° C |
| Working Humidity |
10% - 75% |
Interface & Others
| Operating Systems |
Windows 98/SE/ME/2000/XP, MAC 9.0 higher Linux 2.4 higher |
| PC Inerface |
USB 2.0 (USB 1.1 compatible) |
| HDD Type |
3.5" IDE HDD |
| HDD File System |
FAT32, NTFS |
| TV Type |
PAL, NTSC |
| Supported Formats |
Movie |
MPEG 1, 2, 4 (MPG, MPEG, AVI, M2V, DAT, VOB, etc) , WMV9, XviD (Except GMC, Qpel option applied) |
| Music |
MP3, OGG Vorbis, WMA |
| Photo |
JPG, BMP, GIF, PNG |
Video Output
| Composite |
1Ch : 1.0Vp-p (75 ohm load)
|
| Component |
Y : 1.0Vp-p (75 ohm load)
Pr : 0.70Vp-p (75 ohm load)
Pb : 0.70Vp-p (75 ohm load)
|
| S-Video |
Color Signal : 1.0Vp-p (75 ohm load)
Luminance Signal : 0.286Vp-p (75 ohm load)
|
Audio Output
| Stereo 2Ch |
Left (1/L), Right (2/R) |
| Digital Out (Coaxial) |
0.5 Vp-p(75 ohm) |
| Audio Sampling Rate |
32, 44.1, 48, 88.2, 96KHz |
| S/N (Signal to Noise) Ratio |
99dB |
| Dynamic Range |
92dB |
| Harmonic Frequency Distortion |
0.01% |
|
|
|
|
