ATI RADEON 9200 PRO 128MB MAC EDITION PCI |
New, Bulk - card only, no box. 90 Day OWC warranty.
| OWC NOTE: ATI states that Mac OS 9.2.2 is required to use this card. However, customers are reporting that older versions of the OS do function with this card, without drivers even needing to be installed.
OWC does not guarantee performance or compatibility with any older systems. We are simply passing on good information for you to make an informed purchase.
Here is a report from an OWC customer:
I ordered two ATi Radeon 9200's over a month ago and was very happy to finally receive them yesterday.
One was for a cross-your-fingers-and-pray project: putting a new Apple 23" aluminum flat panel Studio Display on a PowerMac 9500 running Mac OS 8.6.
The ATi driver software requires Mac OS 9.2 or later.
I am happy to report that the Radeon 9200 connects directly to the FP display an runs flawlessly WITHOUT drivers other than what is inherent under Mac OS 8.6. We also tried this on a 7500 running 9.1 (easier to test since the 9500 is a pig to open, and it worked beautifully there as well.
Thanks for supporting the Mac!
-- Marc
|
- RADEON® 9200 delivers stunning graphics and comprehensive support for Mac enthusiasts, powering the ultimate visual experience for OS X and legacy OS 9 operating systems. Flexible display configurations, a wide variety of industry-standard connections and 128MB of DDR memory ensure that the RADEON® 9200 Mac Edition will support your creativity in gameplay, multimedia and personal productivity applications.
At-a-glance:
• RADEON® 9200 Mac edition delivers stunning graphics with dual display support, specifically designed for OS X and legacy OS 9 systems
• Enhanced visual quality delivers mind-blowing gameplay and multimedia support at an unbeatable value
• Experience ultra-realistic 3D effects with dedicated support for Mac-friendly applications including OpenGL™, Quartz™ and QuickTime™
Features:
- Multi-Generational Technology
• Designed for OS X and legacy OS 9 systems for the widest support of Mac systems
• Flexible dual display configurations that reach resolutions up to 2048x1536
• Use VERSAVISION™ to enable hardware accelerated display rotation – up to 180 degrees
• 128MB of DDR memory ensures stunning graphics for next-generation and legacy games and applications
Advanced Visual Quality
• SMARTSHADER™ enables cinematic quality lighting and shadow effects
• SMOOTHVISION™ delivers the sharpest, clearest textures without sacrificing frame rates
• High-precision programmable pixel and vertex shaders provide ultra-realistic effects
Pixel-Powered Excellence
• Experience the full power of Mac display features in OS X, OpenGL, Quartz and QuickTime
• Enable high quality settings to customize the gaming experience
• VIDEO IMMERSION™ integrates features to provide unprecedented support for digital and high definition video.
-
-
-
|
Product Specifications:
- Graphics Features
* SMARTSHADER™
* SMOOTHVISION™
* HYPER Z II™
* VIDEO IMMERSION II™
* High Performance Memory Support
* Integrated Transformation, Clipping and Lighting
* Twin Cache Architecture
* SuperScalar Rendering
* Single-Pass Multi-texturing
* True Color Rendering
* Triangle Setup Engine
* Texture Cache
* Bilinear/Trilinear Filtering
* Full-Scene Anti-aliasing
* Texture Compositing
* Texture Decompression
* Specular Highlights
* Perspectively Correct Texture Mapping
* Mip-Mapping
* Z-buffering and Double-buffering
* Emboss, Dot Product 3 and Environment bump mapping
* Spherical, Dual-Paraboloid and Cubic environment mapping
* Fog effects, texture lighting, video textures, reflections, shadows, spotlights, LOD
* biasing and texture morphing
* Programmable Vertex Shader
* Programmable Pixel Shader
* DVD playback
Advanced Dual Display Support
• Drive two displays simultaneously with independent resolutions and refresh rates
• VERSAVISION™ provides hardware accelerated display rotation and scaling
Specifications
• RADEON 9200 VPU
• 128MB DDR memory
• Dual Integrated 10-bit per channel 400MHz DACs
• Integrated 165MHz TMDS transmitter
• Integrated TV-Out supports up to 1024x768 resolution
• Multiple Display connections
• DVI-I port
• VGA port
• S-Video port
• RoHS Compliant
System Software Support - See OWC note at top of page for expanded compatibility
* Mac OS® 9.2.2*
* Mac OS® X 10.2.8
* Mac OS® X 10.3.3 or later
System Requirements - See OWC note at top of page for expanded compatibility
• Supported Mac OS version
• Power Mac G3, G4 or G5 (with available PCI slot)**
• 256MB of system memory
• Installation software requires CD-ROM drive
• DVD-playback requires DVD drive
Warranty
* 90 Day OWC warranty
From ATI Technote 4591 (no longer on ATI/AMD's new website)
- * Mac OS 9 not supported with RADEON 9200 MAC EDITION on Gigabit Ethernet and Digital Audio Power Mac G4 systems
- The information in this article applies to the following configurations:
- RADEON 9200 MAC EDITION
"Gigabit Ethernet" Power Mac G4 model
"Digital Audio" Power Mac G4 model
Mac OS 9.2.2
The RADEON 9200 MAC EDITION may cause the system to hang when booting into Mac OS 9. Moving the board to a different PCI slot or rearranging the existing PCI cards in your system may remedy the problem.
- This is not an issue on Mac OS X or other G4 based systems.
Analog monitor display modes *
Resolutions and maximum refresh rates (Hz) in thousands and millions of color settings
| Monitor
Resolution |
Maximum Refresh
Rates (Hz) |
|
640 x 480
|
200
|
| 720 x 480 |
200 |
|
800 x 600
|
200
|
| 832 x 624 |
200 |
|
1024 x 768
|
200
|
|
1152 x 864
|
200
|
| 1152 x 870 |
200 |
|
1280 x 960
|
200
|
|
1280 x 1024
|
150
|
| 1600 x 900 |
150 |
|
1600 x 1024
|
150
|
|
1600 x 1200
|
120
|
|
1792 x 1344
|
75
|
|
1856 x 1392
|
75
|
|
1920 x 1080
|
120
|
|
1920 x 1200
|
76
|
|
1920 x 1440
|
90
|
| 2048 x 1152 |
100 |
| 2048 x 1280 |
100 |
|
2048 x 1536
|
85
|
Digital Flat Panel Maximum resolution and refresh rate:
| Monitor
Resolution |
Maximum Refresh Rate (Hz) |
|
1920 x 1200
|
60
|
* Actual available display modes are dependent upon monitor selection.
|
