Perfect for recording on the go!
- USB powered - no external AC power supply necessary.
- Low power usage for minimal laptop battery drain.
- Ready to use out of the box- bundled with Steinberg Cubase LE recording software.
|
Click to enlarge |
|
|
 The ultimate in portability and durability
Designed as the ideal Audio/MIDI companion to notebook computer-based recording environments, the iO|2 USB has a compact form factor that can easily fit in a laptop case or small backpack. The iO|2 USB features durable aluminum casing, USB power (eliminating cumbersome external power supplies) and is optimized for minimal laptop battery drain.
The iO|2 provides 2-channels of pristine 24-bit/48kHz audio directly to your computer via the integrated USB interface and features 2 channels of switchable mic/line inputs. And with Hardware Direct Monitoring, you never have to worry about dealing with audio latency while recording.
Small enough to fit in a backpack, but powerful enough to get the job done right, the iO|2 is perfect for musicians on the go.
|
| FREQUENCY RESPONSE:
|
MIC/LINE IN
to SPDIF/USB OUT: |
+/-0.1dB Input Gain = minimum |
MIC/LINE IN
to MAIN OUT (through ADC/DAC) |
+/-0.35dB Input Gain=minimum |
| SIGNAL-TO-NOISE RATIO (SNR):
|
MIC/LINE IN (balanced)
to INSERT OUT: |
110dB A-weighted,
input impedance at XLR or 1/4" jack = 600 Ω,
Input Gain = minimum |
GUITAR IN (unbalanced)
to INSERT OUT: |
99dB A-weighted,
input impedance at 1/4" jack = 600 Ω,
Input Gain = minimum |
MIC/LINE IN (balanced)
to SPDIF/USB OUT: |
99dB A-weighted,
input impedance at MIC or LINE jack = 600 Ω,
Input Gain = minimum |
GUITAR IN (unbalanced)
to SPDIF/USB OUT: |
94dB A-weighted,
input impedance at 1/4" jack = 600 Ω,
Input Gain = minimum |
MIC/LINE IN (balanced)
to MAIN OUT (through ADC/DAC): |
97dB A-weighted,
input impedance at MIC or LINE jack = 600 Ω,
Input Gain = minimum |
MIC/LINE IN (balanced)
to MAIN OUT (through direct monitor): |
95dB A-weighted,
input impedance at MIC or LINE jack = 600 Ω,
Input Gain = minimum |
| TOTAL HARMONIC DISTORTION + NOISE (THD+N):
|
MIC/LINE IN (balanced)
to INSERT OUT: |
<0.001% Input Gain = minimum,
1KHz input signal,
INSERT OUT = 5.7dBV |
GUITAR IN (unbalanced)
to INSERT OUT: |
0.034% Input Gain = minimum,
1KHz input signal,
INSERT OUT = 5.3dBV |
MIC/LINE IN (balanced)
to SPDIF/USB OUT: |
0.003% Input Gain = minimum,
1KHz input signal,
DIGITAL OUT = -0.3dBFS |
GUITAR IN (unbalanced)
to SPDIF/USB OUT: |
0.034% Input Gain = minimum,
1KHz input signal,
DIGITAL OUT = -0.7dBFS |
MIC/LINE IN (balanced)
to MAIN OUT (through ADC/DAC): |
0.005% Input Gain = minimum,
1KHz input signal,
MAIN OUT = 5.6dBV |
MIC/LINE IN (balanced)
to MAIN OUT (through direct monitor): |
0.006% Input Gain = minimum,
1KHz input signal,
MAIN OUT = 5.6dBV |
|
Features:
- MIDI Input/Output
- 24-bit, 48 kHz operation with high-end A/D and D/A conversion through integrated USB audio interface
- 2 XLR mic inputs with 48V phantom power plus 2 1/4" balanced line inputs that can accept guitar level signals
- 1/4" balanced main outputs
- 1/4" TRS inserts on input channels
- 1/4" TRS headphone output
- Dedicated four segment signal/clip LED meter on both channels
- Ultra low-latency ASIO 2.0 drivers (with zero-latency hardware monitoring)
- 24-bit S/PDIF I/O for direct digital recording
- Mac OS X, Windows XP (32-bit) and Vista (32-bit) compatible
Note for Mac users:
The iO|2 is a class-compliant Mac device, meaning that no drivers are necessary for the Mac. Just plug the iO|2 in to your Mac, and it will install automatically.
Dimensions:
- Length: 7.25" (184.15 mm)
- Weight: 8 oz. (226.8 g)
Warranty:
|
