System Requirements
- Macintosh computer with Intel Core processor
- 512 MB of RAM
- Built-in USB 2.0 port
- Mac OS X 10.5.6 Leopard (or later)
- QuickTime 7.6 (or later)
- Internet connection required to download Program Guide data.
Note: 720p or 1080i HD features require an Intel Core 2 Duo processor. Analog TV recorded and processed by a software encoder; quality depends on processor performance.
Connections
| Size and Weight |
|
| turbo.264 HD |
EyeTV Hybrid |
- Height: 10 mm
- Width: 30 mm
- Depth: 73 mm
- Weight: 18 g
|
- Height: 15 mm
- Width: 32 mm
- Depth: 82 mm
- Weight: 30 g
|
turbo.264 HD Technical Specifications
Input formats
AVCHD Video, QuickTime, AVI, DV, WMV, MPEG-1, MPEG-2 Program/Transport Stream, MPEG-4, MP4, M4V, H.263, H.264 AVC, Xvid, VIDEO_TS and many more.
Output formats
Apple TV Video:
Video: H.264 Main Profile, 5 Mbps max., 1280×720 pixels at 24 fps max. or 960×540 pixels at 30 fps max., Audio: AAC-LC, stereo, 160 Kbps, 48 kHz. When exporting to Apple TV format, for sources that contain Dolby Digital™ AC-3 audio, the digital audio will be passed through into the resulting file.
iPod High Video:
H.264 Baseline Profile Low-Complexity, 1.5 Mbps max., 640×480 max., 30 fps max. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: If the source movie is larger than 640×480 it will be scaled to fit within 640×480 preserving aspect ratio. Resolution is maintained if 640×480 or smaller. Frame rate is maintained when 30 fps and smaller.)
iPod Standard Video:
H.264 Baseline Profile (up to Level 1.3), 768 kbps max. 320×240 max., 30 fps max. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: If the source movie is larger than 320×240 it will be scaled to fit within 320×240 preserving aspect ratio. Resolution is maintained if 320×240 or smaller. Frame rate is maintained when 30 fps and smaller.)
iPhone Video:
H.264 Baseline Profile (up to Level 1.3), 900 kbps max. 480×360 max., 30 fps max. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: If the source movie is larger than 480×360 it will be scaled to fit within 480×360 preserving aspect ratio. Resolution is maintained if 480×360 or smaller. Frame rate is maintained when 30 fps and smaller.)
Sony PSP Video:
H.264 Main Profile, 1.5 Mbps, 480×270, 30 fps. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: A source with 16:9 aspect ratio will produce a 480x270 destination movie while a 4:3 video results in a 362x272 file.)
YouTube Video:
H.264 Baseline Profile Low-Complexity, 1.5 Mbps max., 640×480 max., 30 fps max. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: If the source movie is larger than 640×480 it will be scaled to fit within 640×480 preserving aspect ratio. Resolution is maintained if 640×480 or smaller. Frame rate is maintained when 30 fps and smaller.)
YouTube HD Video:
H.264 Main Profile, 5 Mbps max., 1280×720 max., 30 fps max. Audio: AAC-LC, stereo, 128 Kbps, 48 kHz. (Note: If the source movie is larger than 1280×720 it will be scaled to fit within 1280×720 preserving aspect ratio. Resolution is maintained if 1280×720 or smaller. Frame rate is maintained when 30 fps and smaller.)
HD 720p:
Video: H.264 Main Profile, 10 Mbps max., 1280×720 pixels at 30 fps max., Audio: AAC-LC, stereo, 160 Kbps, 48 kHz (Note: If the source movie is larger than 1280×720 it will be scaled to fit within 1280×720 preserving aspect ratio. Resolution is maintained if 1280×720 or smaller. Frame rate is maintained when 30 fps and smaller.)
HD 1080p:
Video: H.264 Main Profile, 10 Mbps max., 1920×1080 pixels at 30 fps max., Audio: AAC-LC, stereo, 160 Kbps, 48 kHz
Custom profiles:
H.264 High Profile, 1080p, 30 fps, 10 MBit/s max.
EyeTV Hybrid Technical Specifications
EyeTV Hybrid comes with a state-of-the-art Xceive 5000 silicon tuner and next-generation demodulator technology for superior reception, including FM radio support.
- Frequency Range: 48-801 MHz (VHF and UHF)
- Analog TV Standards: NTSC
- Digital TV Standards: ATSC, Clear QAM
- FM Radio
- USB 2.0
- Antenna input: Standard F connector
- S-Video (via break out cable, included)
- Composite video (via break out cable, included)
- Stereo audio (via break out cable, included)
- IR remote control sensor
Warranty: 1 Year Manufacturer Warranty |
