Wireless Compatibility

Since the Bridge is based on dual-band
Wireless-N, it works with any device supporting Wi-Fi standards, and is compatible with Wireless-G, -A, and -B. Connect digital video recorders, set-top boxes or computers to your Wireless-N network. Convert your wired-Ethernet printer, scanner, camera, storage device, notebook, or desktop for wireless connectivity.

Windows, Mac and Linux

The Wireless-N Ethernet Bridge works on any platform and under any operating system. Since there's no drivers to load, setup is a snap – configure the network settings through your PC's web browser, then plug it into your device and go.

Simple Setup

To protect your data and privacy, all wireless transmissions can be encrypted with industrial-strength Wi-Fi Protected Access (WPA) security. Wi-Fi Protected Setup™ helps make secure connections pushbutton simple.

Minimum Requirements

• Device with Ethernet port
• Wireless Access Point or Router (802.11g, 802.11b, 802.11a, or draft 802.11n compliant)
• Internet Explorer 6, or Firefox 2 or higher for browser-based coniguration
• PC with CD-ROM drive (for Setup Wizard only)
• Setup Wizard requires Windows XP, Vista, or Vista 64-bit edition with latest updates

Tech Specs

• Model: WET610N
• Standards: IEEE 802.3u, 802.11g, 802.11b, 802.11a, draft 802.11n
• Ports: Ethernet, Power
• Buttons: Reset, Wi-Fi Protected Setup™
• LEDs: Power, Ethernet, Wi-Fi Protected Setup™, Wireless
• Cabling Type: CAT 5e
• Number of Antennas: 3 (internal)
• Connector Type: RJ-45
• Detachable (Y/N): No
• Modulations:
  • 802.11a: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
  • 802.11b: CCK/QPSK, BPSK
  • 802.11g: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
  • 802.11n: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
• RF Power (EIRP) in dBm:
  • 802.11a: 15dBm (typical) @ 54Mbps
  • 802.11b: 18dBm (typical) @ 11Mbps
  • 802.11g: 16dBm (typical) @ 54Mbps
  • 802.11n: 12dBm (typical) @ 130Mbps (HT20), 270Mbps (HT40)
• Receive Sensitivity in dBm:
  • 802.11a: -72dBm (typical) @ 54Mbps
  • 802.11b: -85dBm (typical) @ 11Mbps
  • 802.11g: -73dBm (typical) @ 54Mbps
  • 802.11n: -70dBm (typical) @ MCS15/2.4GHz, -69dBm (typical) @ MCS15/5.0GHz
• Antenna Gain in dBi: 1
• Wireless Security: WEP, Wi-Fi Protected Access™ 2 (WPA2)
• Security Key Bits: Up to 128-bit encryption

Key Features

• Add Wireless-N (802.11n draft 2.0) network connectivity to any wired-Ethernet device
• Complies with IEEE 802.11n draft 2.0 (2.4 GHz and 5 GHz), 802.11g, 802.11b and 802.11a standards
• Wi-Fi certiied to ensure interoperability
• Works without drivers on Windows®, Macintosh®, Linux® and game consoles—anything with an Ethernet port!
• Industrial-strength wireless encryption WPA2™ to ensure security
• Easy-to-use setup wizard
• Equipped with one 10/100 auto-crossover (MDI/MDI-X) port

Environmental Details

• Dimensions: 5.71" x 4.17" x 2.05" (145 x 106 x 52 mm)
• Unit Weight: 5.61 oz (159 g)
• Powe:r 12V, 1A
• Certifications: FCC, UL/cUL, ICES-003, RSS210, Wi-Fi (IEEE 802.11a/b/g/draft n), WPA2™, Wi-Fi Protected Setup™
• Operating Temp: 32 to 104°F (0 to 40°C)
• Storage Tem:. -4 to 140°F (-20 to 60°C)
• Operating Humidity: 10 to 85% Noncondensing
• Storage Humidity: 5 to 90% Noncondensing

Package Contents

• Wireless-N Ethernet Bridge with Dual-Band
• Setup Software and User Guide on CD-ROM
• Quick Installation Guide
• Network Cable
• Power Adapter
