M-Audio Ozonic - 37-Key Audio/MIDI FireWire Interface and Controller (MID99004083500)
|
Same Day
|
$499.00 |
|
|
 |
|
Ozonic
37-Key audio/MIDI FireWire Interface and Controller
True Plug-and-Play USB MIDI keyboard and Interface for Mac OSX and Windows desktops.
|
|
|
Ozonic combines a keyboard, control surface and 24-bit/96kHz FireWire audio interface in a completely integrated mobile audio/MIDI production and performance tool that streamlines making music with your computer—anywhere, anytime. Features like a professional synth-action keyboard with three assignable zones and 40 assignable MIDI controllers complete with transport buttons make it ideal for harnessing the full potential of your software studios. The built-in FireWire audio interface with mic/instrument preamps and headphone monitoring lets you work with loops and layer your own vocals, guitars and more. Dual output pairs with headphone A/B source monitoring is perfect for pre-listening, and cueing in a live performance. Ozonic is your answer to getting the most from your music software..
 |
|
|
Main Features:
- 37-note velocity-sensitive keyboard
- 4 x 4 analog I/O; headphone out
- 1 x 1 MIDI I/O
- 40 fully assignable MIDI controllers
- FireWire bus power
 Specifications
General
- Sample Rates – 44.1, 48, 88.2, and 96 kHz
Line Inputs
- Max Input – +1.5 dBV (1.183 Vrms) @48kHz, +2.3 dBV (1.310 Vrms) @ 96 kHz
- Signal to Noise Ratio – -106 dB (a-weighted)
- Dynamic Range – 106 dB (a-weighted)
- THD + N – 0.00266%
- Frequency Response – +/-0.3 dB, 20Hz to 40kHz @ 96kHz
- Crosstalk – -108 dB
- Impedance – 10k Ohms
Microphone Input
- Available Gain – 42 dB
- Signal to Noise Ratio – -103 dB (a-weighted)
- Dynamic Range – 103 dB (a-weighted)
- THD + N – 0.00188%
- Frequency Response – +/-0.4 dB, 20Hz to 40kHz @ 96 kHz
- Impedance – 3.5k Ohms
- Instrument Input Available Gain – 35 dB
- Signal to Noise Ratio – -100 dB (a-weighted)
- Dynamic Range – 100 dB (a-weighted)
- THD + N – 0.00215%
- Frequency Response – +/-0.4 dB, 20Hz to 40kHz @ 96 kHz
- Impedance – 200k Ohms
Line Outputs
- Max Output (balanced) – +10.2 dBu (2.524 Vrms)
- Signal to Noise Ratio – -105 dB (a-weighted)
- Dynamic Range – 105 dB (a-weighted)
- THD + N – 0.00319%
- Frequency Response – +/-0.3 dB, 20Hz to 40kHz @ 96 kHz
- Crosstalk – -122 dB
- Impedance (balanced) – 300 Ohms
Headphone Outputs
- Max Output – -2.1 dBV (0.784 Vrms) into 32-ohms
- Signal to Noise Ratio – -105 dB (a-weighted)
- Dynamic Range – 105 dB (a-weighted)
- Frequency Response – +/-0.3 dB, 20Hz to 40kHz @ 96 kHz
- Output Impedance – 75 OhmsWorking Headphone Impedance – 32 to 600 Ohms
back to top
|
Audio
- 4 x 4 24-bit/96kHz analog I/O with
- mic input with phantom power (XLR)
- instrument input (1/4” TS)
- stereo line inputs (1/4” TS)
- 2 pairs of outputs (1/4” TRS and TS) with volume sliders
- headphone level knob
- headphone A/B source select knob
- direct hardware monitoring with level control
- flexible software routing of any input pair to any output pair
- dual concentric gain control knob with signal/clip indicators
- powered via FireWire bus or 12V DC adapter
MIDI
- 37-note, full-size, velocity-sensitive, synth-action keyboard with assignable aftertouch
- 1 x 1 MIDI I/O
40 assignable MIDI controllers including:
- 4-way joystick
- 8 MIDI controller knobs
- 9 MIDI controller sliders with drawbar mode
- 9 MIDI buttons
- 5 transport control buttons
- pitch and mod wheels
- aftertouch
- sustain pedal input
- expression pedal input
- 20 non-volatile memories
- +/- octave and +/- transpose buttons
- all MIDI controllers fully programmable to MIDI controller number and unique MIDI channel
- controller mute function mutes controller output to avoid parameter jumps
- SysEx memory dump; compatible with Enigma editor/librarian software (included) for managing and storing unlimited setups
- MIDI controller assignments:
- MIDI controller number
- RPN/NRPN
- pitch bend
- GM/GM2/XG SysEx messages
- MIDI button assignments:
- note on; note off; note on/off toggle
- MIDI CC on/off toggle
- program, bank LSB, bank MSB presets
- MIDI Machine Control functions
- GM/GM2/XG SysEx messages
|
|
