Pro Audio Firewire 800 PCI Card
FireWire is now twice as fast. The EZQuest FireWire 800 PCI card allows you to harness the latest in FireWire technology. The FireWire 800 PCI card allows speeds of up to 800Mbits/s (see specs for operating system requirements.) The EZQuest PCI card has three super fast 9-pin FireWire 800 ports for your newer devices. Complete and ready to install the EZQuest FireWire 800 PCI card is the latest and greatest in high speed connectivity.
| PCI Card Specifications |
|
| Ports: |
3 x 9-pin FireWire 800/1394b Ports |
| Interface: |
33MHz / 64bit and 33MHz / 32bit
selectable PCI interface |
| Version: |
PCI 2.2 Compliant |
| Maz Cable Hops: |
16 over 4.5 meters |
| Digital Video: |
Full Support |
| Controller: |
OHCI Compliant IEEE 1394b Controller |
| Cable Power: |
12V, 9W max from PCI Bus
24V, 30W max with internal connector |
| Protocols: |
Function Control Protocol (FCP)
Connection Management Protocol (CMP) |
| Included Hardware: |
PCI Card |
| Included Software: |
1394b Drivers for Mac & PC |
| Transfer Rates: |
800 Mbits/s (Mac OS X 10.2.4 or later,
Windows 98SE*, ME*, 2000*, XP*) |
| Dimensions: |
6 3/4" x 2 3/4" |
| Warranty: |
1 Year |
|
EZQuest FireWire 800 PCI Card
