Full Features
- 2 x 2 16-bit/48kHz analog I/O
- 2 microphone inputs (XLR balanced) with 48v phantom power
- stereo microphone input (1/8”)
- 2 high-impedance instrument/line inputs (balanced/unbalanced 1/4” TRS)
- 2 mono line outputs (1/4” @ -10dBV)
- stereo line output (1/8”)
- stereo headphone output with level control knob
- gain control knob for each input channel (+40 dB max)
- zero-latency hardware direct monitoring (mono/stereo) with software level control
- USB-powered for total mobility
- includes Ableton Live Lite music production software, so you can make music right away
Specifications
- sampling rates (kHz)
- 8, 9.6, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48
- frequency response
- signal-to-noise ratio
- dynamic range
- THD
- 0.013% (-78 dB) @ -1dBFS, 1kHz
- USB recording
- 16-bit/44.1kHz > 2-in/2-out
- 16-bit/48kHz > 2-in/2-out
1 year manufacturer warranty
|
System Requirements
Compatibility
- ASIO 2
- MME
- Sound Manager
- DirectX
- Mac OS X Core Audio / Core MIDI
Minimum System Requirements (PC)
- Windows 98SE / Me / 2000 (SP4) / XP (SP2)*
- Pentium II 350 w/ 64MB RAM
* Home and Professional Edition only. Windows Media Center Edition is not currently supported.
** M-Audio suggests you also check the minimum system requirements for your software,
as they may be greater than the above.
Minimum System Requirements (Mac)
- G3* 300MHz/G4* 350MHz
- OS 9.2.2, 64MB RAM;
- OS X 10.2.6, 10.3.6, 10.4, 10.5.1 w/ 128MB RAM**
* native USB port required; G3/G4 accelerator cards not supported
** M-Audio suggests you also check the minimum system requirements for your software,
as they may be greater than the above.
|
