Description: Ships: Price:
1.0TB NewerTech Guardian MAXimus RAID-1 [MIRROR] (1.0TB HDs x 2) eSATA, FireWire 800+400, USB 3.0 Multi-Interface Solution. Oxford 946DSE/3100 Chipset, 7200RPM Drives, 64MB Data Buffer. All Cables & Software Bundle. 3 Year NewerTech Limited Warranty. (GM3Q7H10TB64)

Get $6.99 off of an Apple Thunderbolt to FireWire 800 Adapter when purchased with any qualifying FireWire 800 product.
Click Here for qualifying items
----
Additional Offer also available:
----
This item qualifies for the ProSoft Drive Genius Special, only $29 - That's 70% off retail!
Offer will be shown in basket once this item is added.
Same Day $287.99
OWC Discounted Price: $257.99
Rating: 4.6 based on 9 reviews.
Add to Your Basket:


NewerTech Guardian MAXimus

1.0TB Multi-Interface Hardware RAID-1
(Mirrored) Data Redundant Solution

Mac / PC / USB 3.0 & 2.0 / FireWire 800 / FireWire 400 / eSATA
  • Mac
  • PC
  • eSATA
  • FireWire 800/400
  • USB 3.0
Provides "live activity" backup/data redundancy
of your critical data with Plug and Play
simplicity on any Mac or PC.
MAXimum Performance & Compatibility
Underneath Guardian MAX's sleek, unassuming housing beats the heart of a super protector ready to save large amounts of precious data quickly, reliably, and effortlessly. Pre-configured hardware RAID solutions feature two paired lightning fast SATA 1.5/3.0Gb/s drives with up to 1.0TB each of storage capacity and a high speed Custom Oxford 946DSE/3100 Integrated Chipset featuring FireWire 800/400, USB 3.0, and eSATA ports to deliver some of the fastest single drive transfer rates possible...up to 300MB per second! Enclosure only kits are also available for "add your own hard drive" flexibility and economy With its multiple interface connections, Guardian MAXimus makes adding vault-like mirrored data storage performance to Macintosh and Windows computers Plug and Play easy.
MAXimum Real Time Redundancy
Real performance can also be measured by intangibles like having peace of mind knowing your critical data is always safe! Should you experience a hard drive failure, the ever vigilant Guardian MAXimus automatically and seamlessly continues data read/write functions with the remaining drive. And with the convenient front panel drive status LEDs, you'll know at a glance which drive is being accessed and if you need to take any action.
Why You Need Guardian MAXimus RAID-1
Guardian MAXimus is "live activity" backup of financial records, medical files, business projects...any critical data that you simply cannot risk losing. It's always guarding against data loss by writing the same information in real-time to two separate drives for a "mirrored" copy. It also protects you from costly system downtime and data restoring after a single hard drive-equipped system crash. Even daily scheduled software driven data backups can't protect you from the time of your last backup and when your computer's internal drive fails.
Includes the Powerful SpeedTools Utility Suite for Mac
The comprehensive Mac utility used by professionals for accurate Mac diagnosis and maintenance. Click the SOFTWARE tab below to learn more »

Includes

Newertech Guardian MAXimus includes
  • External NewerTech Guardian MAXimus storage solution
  • 39" High Quality Double Shielded eSATA connecting cable
  • 36" High Quality Double Shielded FireWire 800 connecting cable (9-9 Pin cable)
  • 36" High Quality Double Shielded FireWire 400 black connecting cable (6-6 Pin cable)
  • 36" High Quality Double Shielded USB 3.0 connecting cable
  • UL Listed U.S./International Auto Switching 100 ~ 240v, 50/60Hz input, 12 Volt 5 Amp output Power Supply (adapter plugs for International use sold separately). For replacement power supply, click here.
  • Pre-installed Backup and Utility software
    • Intech® SpeedTools Utilities™ OEM (For Mac OS 8.6 - X only)
    • Prosoft Engineering® Data Backup for Mac OS X v10.2.8 or later
    • NovaStor NovaBACKUP® for Windows 2000 or later
  • Over 1.5GB of Freeware/Shareware/Public domain software pre-installed
  • Guardian MAXimus Assembly Manual & User Guide (4.3MB PDF)
  • NewerTech 3 Year Solution Warranty with 48-Hour Turnaround Time
  • Complimentary 1 Year Level 1 Data Recovery

Features

  • 1.0TB + 1.0TB (Mirrored) SATA Hard Drive Storage Solution
  • 64MB Total drive cache
  • Two FireWire 800 9 pin ports
  • One FireWire 400 6 pin port
  • One USB 3.0 "B" port -backwards compatible with USB 2.0/1.1
  • One eSATA port
  • Front panel drive status LEDs
  • Thermalregulated Smart Fan for super quiet operation
  • Shock resistant design

Gallery

Product Specifications:

Drive Type

  • Two paired (identical) 3.5″ SATA devices

Bridge Chipset

  • Custom Oxford 946 eSATA, FW400(1394A), FW800(1394B), and USB 3.0 Integrated Chipset

Standard Mechanism

    1.0TB Toshiba / HGST Deskstar 7K1000.D Specifications:

    Specifications

    Form Factor
    3.5″ HDD
    Interface
    SATA 6.0Gb/s
    Capacity1
    1.0TB
    Formatted Capacity2
    931GiB
    Rotational Speed
    7,200 RPM
    Cache / Data Buffer
    32MB
    Manufacturer Model Number
    HDS721010DLE630
    Format

    Physical

    Height (max)
    26.1mm (1.027″)
    Width (max)
    101.6mm (4.0″)
    Length (max)
    147mm (5.787″)
    Weight (typical)
    450g (0.992 lbs.)
    Bytes per Sector
    512
    Areal Density
    569Gb/in2

    Reliability3

    Contact Start-Stops
    300,000
    Nonrecoverable Read Errors
    1 per 1014 bits read
    Warranty
    2 Year Warranty

    Performance

    Transfer Rate (Max)
    3.0Gb/s

    Power

    Maximum Start Current, DC
    2.0 Amps
    Idle Mode
    3.7 Watts

    Environmental (Operating)

    Shock
    70 G max at 2ms
    Ambient Temperature (°F)
    32°F to 107°F
    Ambient Temperature (°C)
    0°C to 42°C
    Vibration
    0.67 G (5 to 500 Hz)
    Relative Humidity (non-condensing)
    8% to 90%
    Altitude
    -304.8 m to 3,048 m (-1,000 ft to 10,000+ ft)

    Environmental (Non-Operating)

    Shock
    350 G max at 1ms
    Ambient Temperature (°F)
    -40°F to 158°F
    Ambient Temperature (°C)
    -40°C to 70°C
    Vibration
    1.04 G (5 to 500 Hz)
    Relative Humidity (non-condensing)
    5% to 95%
    Altitude
    -304.8 m to 12,192 m (-1000 ft to 40,000+ ft)

    Acoustics

    Idle (Typical)
    2.5 bels
    1. 1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.
    2. In terms of standard gigabytes, 1GiB ≈ 1.074GB and refers to the actual formatted capacity of shown under Mac OS 10.5 or earlier and Microsoft Windows OS.
    3. Specific application environments such as temperature and duty cycle will affect the overall reliability rates.
  • 2 x 1.0TB* Toshiba/HGST Deskstar™ 7K1000.D Hard Disk Drive**

    *1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.

    **OWC reserves the right to replace or upgrade to equivalent or better components.

Drive Rotation Speed

  • 7200 RPM

Drive Cache Size

  • 64 Megabyte (2 Drives with 32MB (32,768K) cache each)

Maximum Data Transfer Rate

  • USB 3.0 - 300MB/s
  • eSATA - 300MB/s
  • FireWire 800 - 100MB/s
  • FireWire 400 - 50MB/s
  • USB 2.0 - 60MB/s

Port/Interface Bootability

    Can I use this solution as an external startup drive?
  • eSATA: Supported on Macs and PC's meeting minimum requirements. - Click for more info
  • FireWire 800: Supported on Macs and PC's meeting minimum requirements. - Click for more info
  • FireWire 400: Supported on Macs and PC's meeting minimum requirements. - Click for more info
  • USB 2.0: Supported on Macs and PC's meeting minimum requirements. - Click for more info

Macintosh System Requirements

  • Mac OS 8.6 to 9.2.2 compatible, OS X 10.1.x and later. Including 'Mavericks' 10.9.x (10.2 or later required for FW800 and USB 3.0)
  • eSATA: Macintosh with eSATA interface, either built in or via PCI eSATA card.
  • FireWire 800: Macintosh with FireWire 800 interface, either built in or via PCI FireWire 800 card.
  • FireWire 400: Macintosh with FireWire 400 interface, either built in or via PCI FireWire 400 card.
  • USB 3.0: Macintosh with USB 3.0 interface, either built in or via PCI USB 3.0 card.
  • USB 2.0: Macintosh with USB 2.0 interface, either built in or via PCI USB 2.0 card.

Windows System Requirements

  • eSATA: PC with eSATA interface, either built in or via PCI eSATA card.
  • FireWire 800: PC with FireWire 800 interface, either built in or via PCI FireWire 800 card.
  • FireWire 400: PC with FireWire 400 interface, either built in or via PCI FireWire 400 card.
  • USB 3.0: PC with USB 3.0 interface, either built in or via PCI USB 3.0 card.
  • USB 2.0: PC with USB 2.0 interface, either built in or via PCI USB 2.0 card.

Linux Requirements

  • Linux compatible via supported USB and FireWire interfaces.

Recommended eSATA Cards

Recommended USB 3.0 Cards

Power Supply

Format

Software Included

Enclosure Size

  • 8.97″(D) x 2.88″(W) x 5.25″(H)
  • 227.84mm x 73.15mm x 133.35mm

Enclosure Weight (no accessories)

  • 2.335lbs. (1.059kg) (bare enclosure)

Product Manual

Security

  • Kensington™ security slot

Operating Environment:

Temperature

  • (operating) 5°C - 42°C (41°F - 107°F)
  • (non-operating) -40°C - 65°C (-40°F - 149°F)

Relative Humidity

  • (operating) 8% - 90% RH (Non-condensing)
  • (non-operating) 5% - 95% RH (Non-condensing)

Shock

  • 65G 2mS; (non-operating) 175G 2mS

Vibration

  • (operating) 1.0G (5 - 300Hz)
  • (non-operating) 5.0G (5 - 500Hz)

MTBF

  • More than 300,000 power-on hours

Warranty

3 Year NewerTech Solution Limited Warranty

The best warranty is one you never have to use - but should the need occur - we're proud to provide a superior level of support and service coverage to our customers. OWC and NewerTech storage solutions come fully backed by an Industry-leading 48-hour turnaround time which includes complimentary Level 1 data recovery for the first year, plus additional data recovery options available throughout the warranty period, for complete peace of mind ownership confidence.

View more information about the 3 Year NewerTech Solution Limited Warranty

Note: Do not disassemble or otherwise open your NewerTech solution prior to the conclusion of NewerTech's 3 year Limited Warranty period. Doing so will void the remainder of the NewerTech limited warranty.



Manufacturer provided specifications for Newer Technology p/n GM3Q7H10TB64 UPC#: 811643012240

Software

Prosoft Macworld 4.5 mice
Prosoft Engineering® Data Backup 3 for Mac OS X v10.2.8 or later
Backup Made Easy. Data Backup makes it easy to backup to FireWire and USB drives, network drives, CDs and even DVDs. Make schedules so you don't need to 'think' about backing up... It does it for you.
A $59.00 Value! View detailed software info, or click here to purchase software separately from solution
Novastor
NovaStor NovaBACKUP® Solution for Windows®
NovaBACKUP has been helping millions of users recover from data loss and disasters for over 18 years. Feature rich, NovaBACKUP provides a powerful backup solution. Built-in support for hundreds of the most popular storage devices and a step-by-step backup and restore wizard makes NovaBACKUP extremely easy to use. Requires Windows 2000 or later.
A $49.95 Value! View detailed software info
Intech SpeedTools Utilities
Intech® SpeedTools Utilities™
Intech SpeedTools consists of a suite of utilities managed by an application which controls the launching, documentation and version control of each individual component utility, such as Disk Defrag and QuickBack. An easy-to-use installation and removal application is provided to make installation a snap, yet powerful enough to allow you to customize which utility component set you would like to create.
An $89.95 Value! View detailed software info, or click here to purchase software separately from solution
1. The actual total capacity will depend on your own defined file settings/preferences. 1GB = 1,000,000,000 bytes. Total accessible capacity
varies depending upon operating environment (typically 5-10% less).
2. 1MB per 2.4 megapixel JPEG photo - low resolution
3. DVD Quality Digital Video at a 2.597GB/hour data rate
4. 2.85MB per MP3 song
NewerTech 1.0TB Guardian MAXimus RAID-1 Mfr P/N: GM3Q7H10TB64 OWC SKU: NWTGM3Q7H10TB64 Multi-Interface Hardware RAID-1 (Mirrored) Data Redundant Solution 3 Year NewerTech Solution Limited Warranty Ships: Same Day only $257.99 Newer Technology GM3Q7H10TB64 In Stock, Click to Buy Now
