Name: (*) OWC Mercury Elite Pro Dual Two-Bay RAID Thunderbolt + USB 3.2 (5Gb/s) RAID External Storage Enclosure for 3.5-inch SATA Drives
Brand: OWC
SKU: OWCMETB7DK0GB
Rating: 4.61 (84 reviews)

OWC Mercury Elite Pro Dual

We're sorry, but this item is no longer for sale. However, there may be more External Drives & Enclosures items available.

We recommend OWC Mercury Elite Pro Dual Two-Bay RAID Thunderbolt 2 + USB 3.2 (5Gb/s) External Storage Enclosure for 3.5-inch SATA Drives (Mfr P/N: TB2U3MED0GB) from OWC for $229.99 as a suitable alternative.

High-Performance, High-Reliability, Portability, and Style are standard for the OWC Mercury Elite Pro Dual Series!

1 Year OWC Limited Warranty

Reviews (86)

Overview
Includes
Specs
Reviews
Related

High-Performance + Flexible

The OWC Mercury Elite Pro Dual houses two user-supplied drives that can be easily configured in RAID 0, RAID 1**, span, or JBOD/independent modes via the easy-to-use RAID selector switch on the back, while USB 3.0 and Thunderbolt interfaces provide blazing fast access to your data. This feature-packed external drive comes in a durable, heat-dissipating, brushed-aluminum enclosure.

High-Reliability

A blazing fast Thunderbolt chipset unleashes the full potential of two internal drives you choose to install. Get the maximum sustained throughput from your drives with the flexibility of hardware RAID 0, 1, and non-RAID modes to best suit your demanding applications and workflow.

Portability

The OWC Mercury Elite Pro Dual Series is Built to Last, with a quality design and the best components.

Smart Sense

The Compact and Shock-Resistant Design has the Mercury Elite Series going places! In addition, the OWC Mercury Elite Pro Dual series offers two Thunderbolt ports and one USB 3.0 port for easy use with ANY system! The OWC Mercury Elite Pro Dual even includes all needed cables! Power Saving Connection Sensor. A built-in sensor detects when the data cable is disconnected from a Mac or PC's native Thunderbolt or USB interface and automatically spins down the drives to conserve energy during periods of inactivity. Ideal for notebook users who can go mobile without the need to turn it off or unplug the power cord.**

*For RAID 0 or RAID 1 functionality, it is recommended that identical drives be utilized.

**This function is also available through an interface card, provided the card offers hot plug capability. LED and fan will remain on during disk inactivity.

Includes

(1) OWC Mercury Elite Pro Dual External Storage Enclosure
(1) High-Quality, Certified, Double-Shielded 1 Meter
1 Year OWC Limited Warranty

Need an additional power supply? Secondary/replacement power supplies are also available.

Specs

Drive Bays

2 bays supporting: 3.5-inch SATA drives
NewerTech Adaptadriver required for installation of 2.5" drives

Storage Interface

SATA

RAID Capable

RAID Levels Supported

RAID 0
RAID 1
SPAN
JBOD

RAID Features

Hardware RAID

Device Ports

(2) Thunderbolt Ports
(1) USB 3.0 Port

Data Transfer Rate (Maximum)

Thunderbolt : Up to 10Gb/s (or (1250MB/s)
USB 3.2 Gen 1 : Up to 5Gb/s (or 625MB/s)
USB 2.0 : Up to 480Mb/s (or 60MB/s)
USB 1.1 : Up to 12Mb/s (or 1.5MB/s)

Chipset / Controller

Thunderbolt

MTBF (Mean Time Between Failures)

Varies depending on drive mechanism installed

Contact Start Stops

Varies depending on drive mechanism installed

Mac OS Compatibility

Mac OS X 10.6 Snow Leopard
Mac OS X 10.7 Lion
Mac OS X 10.8 Mountain Lion
OS X 10.9 Mavericks
OS X 10.10 Yosemite
OS X 10.11 El Capitan
macOS 10.12 Sierra

PC OS Compatibility

Windows XP
Windows XP 64-bit Edition
Windows XP Professional x64 Edition
Windows Vista
Windows 7 32-bit Edition
Windows 7 64-bit Edition
Windows 8 32-bit Edition
Windows 8 64-bit Edition
Windows 8.1 32-bit Edition
Windows 8.1 64-bit Edition
Windows 10 32-bit Edition
Windows 10 64-bit Edition
Windows Server 2019
Windows Server 2022
Windows 11

External Power Adapter

Power Supply

External UL-listed universal auto-switching power supply
Need an additional power supply? Secondary/replacement power supplies are also available.

AC Input

100-240V, 50-60Hz, 2.0A

DC Output

+12V, 6A

Cooling

(1) cooling fan

Security Slot

Power Button

Power/Activity LED

Housing Color

Black

Housing Material

Aluminum

Dimensions

Height: 13.5 cm (5.3 in)
Length: 22.9 cm (9.0 in)
Width: 7.1 cm (2.8 in)

Weight

1.1 kg (2.43 lbs)

Altitude

Non-Operating: Varies depending on drive mechanism installed

Noise

Varies depending on drive mechanism installed

Customer Reviews

4.6 out of 5

Write a Review

1 star

70%

23%

Still Running Fine

Been using this for 8 years mainly as external storage for photos stored in Lightroom, and the drive is still running fine. Can't ask for much more. I've already cycled through some other drives for time machine or other back up purposes, but the OWC one has been rock solid.

I would recommend this product to a friend!

Verified Purchase.

Casey,

Aug, 4 2022

review of: 8.0TB OWC Mercury Elite Pro Dual Two-Drive RAID Thunderbolt + USB 3.2 (5Gb/s) RAID External Storage Solution

Reviewer:Casey

Response from OWC, Support

Wow Casey we are glad to hear the Mercury Elite Pro Dual has lasted 8 years, while we do have some newer models available if you're ever interested in upgrading. We hope the enclosure continues to serve you well, thanks for being an OWC customer!

Strong and silent

I purchased this to replace the OWC Guardian Maximum RAID unit I had bought a few years earlier, primarily for use as an external drive for my 50K images - the main reason being it has the Thunderbolt connectivity I wanted to take advantage of on my iMac 2012 model. It has worked flawlessly in that time, and I am saddened by Apple's decision to kill Thunderbolt altogether (at least that's my interpretation of my new 27" iMac with Retina display having zero Thunderbolt ports). So now it's connected via USB 3, and still humming along like a champ.
