Description: Ships: Price:
240GB Mercury Electra 3G SSD 2.5" Serial-ATA 7mm 3Gb/s Solid State Drive. Tier 1 NAND Flash storage with 7% Over Provisioned Redundancy. Mac and PC compatible. Built in the USA. 3 Year OWC Limited Warranty. (SSD7E3G240)

Parallels Desktop 10 for only $39.00! Exclusive offer with purchase of OWC SSDs. Run Windows and/or Linux applications from your OS X Desktop!
Click Here for qualifying items
Same Day $174.99
OWC Discounted Price: $141.99
Rating: 5.0 based on 92 reviews.
Add to Your Basket:


OWC

240GB
Mercury Electra™ 3G SSD
2.5" Serial-ATA 7mm Solid State Drive

For High Speed Personal Computing, Home/Office, Gaming, and Personal Photography.
3 Year OWC SSD Limited Warranty
When only the fastest and most reliable Solid State Drive on the market today will suffice for your data storage and backup, look no further than the OWC 240GB Mercury Electra 3G SSD.
The Mercury SSD line features:
  • DuraWrite™ extends the endurance of your Solid State Drive (SSD).
  • Intelligent Block Management & Wear Leveling automatically distributes data evenly across the entire SSD.
  • Intelligent Read Disturb Management spreads the active read/write across the flash components eliminating data corruption caused by constant use.
  • Intelligent "Recycling" for advanced free space management gradually re-writes data across the SSD over time to ensure data never gets corrupted.
  • RAISE™ (Redundant Array of Independent Silicon Elements) protects the data on your drive similar to having a RAID setup.
  • Best-in-Class ECC Protection for longest data retention and drive life.
No Risk, No Hassle 30-Day Money Back Guarantee.
For more information on OWC return policies, click here.

This internal 2.5" SATA SSD delivers the highest transfer speed, endurance, and performance available today.

With sustained reads up to 285MB/s and writes up to 275MB/s, up to 100X greater data protection than enterprise class Hard Disk Drives, and RAISE technology for RAID like data protection and reliability, the OWC 240GB Mercury Electra 3G SSD line delivers unbeatable performance. It's also designed and built in the U.S. from domestic and imported parts and backed by a 3 Year OWC SSD Limited Warranty.
High Performance Internal Storage
Replace your conventional hard drive with a reliable solid state drive. Unlike traditional hard disk drives, OWC SSDs have no moving parts, resulting in a quiet, cool, and highly rugged storage solution that also offers near instantaneous system response.

Includes

  • 240GB Mercury Electra 3G SSD
This OWC SSD Model is compatible with nearly any Mac or PC model with a Serial ATA connection (SATA, SATA 2.0, or SATA 3.0) including: Learn how to find your Mac's model ID
MacBook Pro Unibody
MacBook Pro (15-inch 2012)
(June, 2012)
Model ID: MacBookPro9,1
2.3GHz, 2.6GHz, 2.7GHz
MacBook Pro Unibody
MacBook Pro (13-inch 2012)
(June, 2012)
Model ID: MacBookPro9,2
2.5GHz, 2.9GHz
MacBook Pro Unibody
MacBook Pro (17-inch 2011)
(October, 2011)
Model ID: MacBookPro8,3
2.4GHz, 2.5GHz
MacBook Pro Unibody
MacBook Pro (15-inch 2011)
(October, 2011)
Model ID: MacBookPro8,2
2.2GHz, 2.4GHz, 2.5GHz
MacBook Pro Unibody
MacBook Pro (13-inch 2011)
(October, 2011)
Model ID: MacBookPro8,1
2.4GHz, 2.8GHz
MacBook Pro Unibody
MacBook Pro (17-inch Early 2011)
(February, 2011)
Model ID: MacBookPro8,3
2.2GHz, 2.3GHz
MacBook Pro Unibody
MacBook Pro (15-inch Early 2011)
(February, 2011)
Model ID: MacBookPro8,2
2.0GHz, 2.2GHz, 2.3GHz
MacBook Pro Unibody
MacBook Pro (13-inch Early 2011)
(February, 2011)
Model ID: MacBookPro8,1
2.3GHz, 2.7GHz
MacBook Pro Unibody
MacBook Pro (17-inch Mid 2010)
(April, 2010)
Model ID: MacBookPro6,1
2.53GHz, 2.66GHz, 2.8GHz
MacBook Pro Unibody
MacBook Pro (15-inch Mid 2010)
(April, 2010)
Model ID: MacBookPro6,2
2.4GHz, 2.53GHz, 2.66GHz, 2.8GHz
MacBook Pro Unibody
MacBook Pro (13-inch Mid 2010)
(April, 2010)
Model ID: MacBookPro7,1
2.4GHz, 2.66GHz
MacBook Pro Unibody
MacBook Pro (17-inch Mid 2009)
(June, 2009)
Model ID: MacBookPro5,2
2.8GHz, 3.06GHz
MacBook Pro Unibody
MacBook Pro (15-inch Mid 2009)
(June, 2009)
Model ID: MacBookPro5,4
2.53GHz
MacBook Pro Unibody
MacBook Pro (15-inch Mid 2009)
(June, 2009)
Model ID: MacBookPro5,3
2.66GHz, 2.8GHz, 3.06GHz
MacBook Pro Unibody
MacBook Pro (13-inch Mid 2009)
(June, 2009)
Model ID: MacBookPro5,5
2.26GHz, 2.53GHz
MacBook Pro Unibody
MacBook Pro (15-inch Early 2009)
(March, 2009)
Model ID: MacBookPro5,1
2.66GHz 2.93GHz
MacBook Pro Unibody
MacBook Pro (15-inch Early 2009)
(March, 2009)
Model ID: MacBookPro5,1
2.66GHz 2.93GHz
MacBook Pro Unibody
MacBook Pro (17-inch Early 2009)
(January, 2009)
Model ID: MacBookPro5,2
2.66GHz, 2.93GHz
MacBook Pro
MacBook Pro (17-inch Late 2008)
(October, 2008)
Model ID: MacBookPro4,1
2.5GHz, 2.6GHz
MacBook Pro Unibody
MacBook Pro (15-inch Late 2008)
(October, 2008)
Model ID: MacBookPro5,1
2.4GHz, 2.53GHz, 2.66GHz 2.8GHz
MacBook Pro
MacBook Pro (17-inch Early 2008)
(February, 2008)
Model ID: MacBookPro4,1
2.5GHz, 2.6GHz
MacBook Pro
MacBook Pro (15-inch Early 2008)
(February, 2008)
Model ID: MacBookPro4,1
2.4GHz, 2.5GHz, 2.6GHz
MacBook Pro
MacBook Pro (17-inch Mid/Late 2007)
(June, 2007)
Model ID: MacBookPro3,1
2.4GHz, 2.6GHz
MacBook Pro
MacBook Pro (15-inch Mid/Late 2007)
(June, 2007)
Model ID: MacBookPro3,1
2.2GHz, 2.4GHz, 2.6GHz
MacBook Pro
MacBook Pro (17-inch Core 2 Duo)
(October, 2006)
Model ID: MacBookPro2,1
2.33GHz
MacBook Pro
MacBook Pro (15-inch Core 2 Duo)
(October, 2006)
Model ID: MacBookPro2,2
2.16GHz, 2.33GHz
MacBook Pro
MacBook Pro (15-inch Glossy)
(May, 2006)
Model ID: MacBookPro1,1
2.0GHz, 2.16GHz
MacBook Pro
MacBook Pro (17-inch)
(April, 2006)
Model ID: MacBookPro1,2
2.16GHz
MacBook Pro
MacBook Pro (15-inch)
(January, 2006)
Model ID: MacBookPro1,1
1.83GHz, 2.0GHz, 2.16GHz
MacBook White Unibody
MacBook (Mid 2010)
(May, 2010)
Model ID: MacBook7,1
2.4GHz
MacBook White Unibody
MacBook (Late 2009)
(October, 2009)
Model ID: MacBook6,1
2.26Ghz
MacBook
MacBook (Mid 2009)
(May, 2009)
Model ID: MacBook5,2
2.13GHz
MacBook
MacBook (Early 2009)
(January, 2009)
Model ID: MacBook5,2
2.0GHz
MacBook
MacBook (Late 2008)
(October, 2008)
Model ID: MacBook4,1
2.1GHz
MacBook Unibody
MacBook (Late 2008)
(October, 2008)
Model ID: MacBook5,1
2.0GHz, 2.4GHz
MacBook
MacBook (Early 2008)
(February, 2008)
Model ID: MacBook4,1
2.1GHz, 2.4GHz
MacBook
MacBook (Late 2007)
(November, 2007)
Model ID: MacBook3,1
2.0GHz, 2.2GHz
MacBook
MacBook (Mid 2007)
(May, 2007)
Model ID: MacBook2,1
2.0GHz, 2.16GHz
MacBook
MacBook (Late 2006)
(November, 2006)
Model ID: MacBook2,1
1.83GHz, 2.0GHz
MacBook
MacBook
(May, 2006)
Model ID: MacBook1,1
1.83GHz, 2.0GHz
Mac mini Intel
Mac mini (Late 2012)
(October, 2012)
Model ID: Macmini6,1 & Macmini6,2
2.3GHz, 2.5GHz, 2.6GHz
Mac mini Intel
Mac mini (Late 2012 Server)
(October, 2012)
Model ID: Macmini6,2
2.3GHz, 2.6GHz
Mac mini Intel
Mac mini (Mid 2011)
(July, 2011)
Model ID: Macmini5,1 & Macmini5,2
2.3GHz, 2.5GHz, 2.7GHz
Mac mini Intel
Mac mini (Mid 2011 Server)
(July, 2011)
Model ID: Macmini5,3
2.0GHz
Mac mini Intel
Mac mini (Mid 2010)
(June, 2010)
Model ID: Macmini4,1
2.4GHz, 2.66GHz
Mac mini Intel
Mac mini (Mid 2010 Server)
(June, 2010)
Model ID: Macmini4,1
2.66GHz
Mac mini Intel
Mac mini (Early 2009)
(March, 2009)
Model ID: Macmini3,1
2.0GHz, 2.26GHz
Mac mini Intel
Mac mini (Late 2009 Server)
(October, 2009)
Model ID: Macmini3,1
2.53GHz
Mac mini Intel
Mac mini (Late 2009)
(October, 2009)
Model ID: Macmini3,1
2.26GHz, 2.53GHz, 2.66GHz
Mac mini Intel
Mac mini (Mid 2007)
(August, 2007)
Model ID: Macmini2,1
1.83GHz, 2.0GHz
Full 16 channel Implementation

Release Candidate (RC) firmware set

There are two kinds of firmware for SSDs Mass Production (MP) and Release Candidate (RC). Prior to an MP firmware release, there are beta firmware releases and an RC firmware release. Often, the RC is the same as the MP release, however there can be small changes and bug fixes made between the two. OWC has evaluated the RC for the 6Gb/s SandForce 2281 Processor and found it to be stable with no issues reported during our testing. However, as with any evolutionary product, issues may surface as different usages and configurations are employed and it is important to understand that there will be further updates and revisions.

Since no firmware update is currently offered for the OWC Mercury EXTREME Pro 6G SSD, no update page exists. To see the typical steps involved with a self performed field firmware update, please visit our 3Gb/s product update page at: http://eshop.macsales.com/Customized_Pages/Framework.cfm?page=sf_firmware.html

It is important to note that the current firmware update tool requires the use of Windows XP/Vista/7. OWC is currently working on a Mac OS based update tool, but we do not have an exact availability date.

240GB Mercury Electra 3G SSD Specifications:

Specifications

Controller
SandForce 2181 Series Processor with 7% Over Provisioning
NAND
Tier 1 Asynchronous MLC NAND Flash Memory
Form Factor
Standard 7mm 2.5"
Interface
SATA 3Gb/s
Capacity1
240GB useable capacity
Total Flash Memory Components – 256GB
16GB allocated to real-time data redundancy & error correction
Formatted Capacity2
223GiB
RAID Support
Qualified for single drive and multiple drive production workstation RAID 0/1/10/0+1 and SPAN usage.
SMART Attributes
Standard5
Native Command Queuing
up to 32 commands
Manufacturer Model Number
OWCSSD7E3G240
RoHS Compliant
Yes
Format

Physical

Height (max)
7mm (0.276″)
Width (max)
70.06mm (2.758″)
Length (max)
100.12mm (3.941″)
Weight
77 grams +/- 2 grams
0.170 lbs +/- 2.71 oz

Reliability3

Data Reliability
ECC Recovery: Up to 55 bytes correctable per 512-byte sector
Security
Chip Based Data Encryption: 128-bit AES-compliant
TRIM Support
OS Dependent
Nonrecoverable Read Errors
Less than 1 sector per 1016 bits read
Warranty
3 Year OWC SSD Limited Warranty
(Standard return policy applies.)

Performance

Sustained
Reads (up to)
285MB/s
Sustained
Writes (up to)
275MB/s
Read Incompressible
Data Rate (up to)
208MB/s
Write Incompressible
Data Rate (up to)
235MB/s
Random 4K Read4
Up to 60,000 IOPS
Random 4K Write4
Up to 60,000 IOPS
Read Latency
less than 0.1ms
Write Latency
less than 0.1ms

Environmental (Operating)

Temperature (°F)
32°F to 158°F
Temperature (°C)
0°C to 70°C

Environmental (Non-Operating)

Temperature (°F)
-67°F to 302°F
Temperature (°C)
-55°C to 150°C

Acoustics

Idle (Typical)
0.0 bels
Seek (Typical)
0.0 bels
  1. 1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.
  2. In terms of standard gigabytes, 1GiB ≈ 1.074GB and refers to the actual formatted capacity of shown under Mac OS 10.5 or earlier and Microsoft Windows OS.
  3. Specific application environments such as temperature and duty cycle will affect the overall reliability.
  4. Specifications provided by SandForce.
  5. Temperature reporting is currently an unsupported feature because due to the operating characteristics of SSDs, it is highly unlikely one would ever exceed an OWC Mercury SSD's stated operating temperature ceiling of 158F/70C. However, we are looking into supporting this feature in the future via a firmware update. Firmware updates can be found here: http://eshop.macsales.com/tech_center/OWC/SSD.
Manufacturer provided specifications for Other World Computing p/n SSD7E3G240 UPC#: 794504337655
