0GB Two Drive Internal RAID 0 Enclosure for Mac Pro
The Smallest RAID Drive Enclosure Dedicated to the Mac Pro*

The Pro Drive allows you to directly integrate hardware RAID 0 storage into your Mac Pro. It holds two 2.5 inch hard drives with an embedded controller chip to instantly enable RAID 0 functionality without difficult set ups.
The new Pro Drive is designed to fit both the Xeon and Nehalem Mac Pro systems. With its slide-ready architectural design, the Pro Drive installs and extracts easily just like the original storage drive bays included in the Mac Pro without extra parts to add or install.
*Not compatible with ANY model of OWC SSD. |
 |
|
RAID 0 made easy
The Pro Drive PD2520 model enhances the I/O speed performances by combining the capacity of the two drives enclosed into one large volume to increase the bandwidth of the I/O throughput. In turn, delivering faster speed performance when compared to a standard 3.5 inch hard drive. Simply install drives and it will automatically create the RAID 0 functionality through the embedded hardware RAID controller. |
Internally & externally attachable
Besides using the Pro Drive as a Mac Pro's® internal drive, the PD2520 can also be utilized as an externally attached drive device via high-speed FireWire 800 + USB 2.0 combo connectivity (cables and power supply not included). Designed conveniently for those using Mac Pros, that may also require the same data to be made mobile along with his/her laptop. |
|
| Package Includes |
- Pro Drive Enclosure
- Instruction manual
- Accessory Kit
|
|
|
|
| Specifications |
|
| Manufacturer Part Number |
|
| Interfaces Supported |
- FireWire 800 (FW400 backwards compatible)
- USB 2.0 (1.1 Backwards compatible)
|
| RAID / JBOD Support |
- Speed mode (RAID 0) : Large volume storage with high speed throughput but without
data protection.
|
| Mechanisms Supported |
- Supports two identical 2.5" SATA (Serial ATA) hard drives up to 9.5mm tall and 1.0TB each.
|
| Drive Rotation Speed |
- Varies with drive mechanisms installed
|
| Drive Cache Size |
- Varies with drive mechanisms installed
|
| Port Configuration |
- FireWire 800 - (1) 1394b port
- USB 2.0 - (1) "B" port
|
| Display / Indicators |
- Drive access / Drive failure
|
| Cooling |
|
| Certifications |
|
| Notes |
*Not compatible with ANY model of OWC SSD. |
| Warranty |
2 Year Raidon/Stardom Warranty |
| Physical |
|
| Temperature |
Operating: 5°C ~ 40°C
Non-Operating: -20°C ~ 70°C |
| Humidity |
Operating: 20%RH ~ 80%RH
Non-Operating: 10%RH ~ 90%RH |
| Dimensions |
31mm x 104mm x 156mm |
| Weight |
0.2kg |
|
| Click here to get your Model Identifier number |
| This is compatible with the following Mac Pro models: |
 |
Machines Have Model Identifier MacPro5,1
Mac Pro (Mid 2010 8-Core, 2.4GHz)
(July, 2010)
|
 |
|
Machines Have Model Identifier MacPro5,1
Mac Pro (Mid 2010 Quad-Core, 2.8GHz, 3.2GHz)
(July, 2010)
|
|
|
Machines Have Model Identifier MacPro4,1
Mac Pro (Early 2009 8-Core, 2.26GHz, 2.66GHz, 2.93GHz)
(March, 2009)
|
|
|
Machines Have Model Identifier MacPro4,1
Mac Pro (Early 2009 Quad-Core, 2.66GHz, 2.93GHz, 3.33GHz)
(March, 2009)
|
|
|
Machines Have Model Identifier MacPro3,1
Mac Pro (Early 2008, 2.8GHz, 3.0GHz, 3.2GHz)
(January, 2008)
|
|
|
Machines Have Model Identifier MacPro2,1
Mac Pro (8-core, 3.0GHz)
(April, 2007)
|
|
|
Machines Have Model Identifier MacPro1,1
Mac Pro (Original, 2.0GHz, 2.66GHz, 3.0GHz)
(August, 2006)
|
|
|
|
