• Up to 750GB of bootable, performance disk capacity*
• Large 8MB or 16MB data cache*
• Ximeta NDAS 2011 Network Enabled
• Compact 6.5" x 6.5" x 1.5" size
• One RJ-45 10/100Base-TX Auto MDI/MDI-X port
• One USB 2.0 High Speed port
• LED Status Lights
- Red: Hard drive access and power
- Amber: Network status (LINK)
- Green: 100MBit/s connection
• External 100~240v 50/60Hz UL Listed power adapter - 3A power supply gives you less stress and clean ample power!
• Ethernet RJ-45 and USB cables Included
• Massive passive heat sink to radiate heat away from hard drive
• Smart power switch - NewerTech miniStack NAS will power up and down in tandem with your computer
• Kensington Security Slot designed to allow the NewerTech miniStack NAS to be anchored to a desk
* in pre-configured solutions, "add your own hard drive" kits also available.
Bridge Chipset
• Ximeta NDAS 2011 Network Enabled
Data Cache Size*
• 8MB (80, 160, 250GB models)
• 16MB (320, 400, 500, 750GB models)
* in pre-configured solutions, "add your own hard drive" kits also available.
Enclosure Size
6.5" x 6.5" x 1.5" (16.51cm x 16.51cm x 3.81cm)
Enclosure Weight
Approximately 2.6lbs (bare enclosure only)
Case Material
• High quality aluminum colored plastic
Application
• Up to 750GB of storage from single 3.5" PATA hard drive*
• FAT32/NTFS/HFS+ file formats**
* “Add Your Own Hard Drive” enclosure-only kits also available
** FAT32 can be accessed on Mac & PC, NTFS can be accessed on PC but read only on Mac, HFS+ can be accessed on Mac only.
Operation Environment
• Temperature: (operating) 41°F - 104°F (5°C - 40°C) (non-operating) -4°F - 158°F (-20°C - 70°C)
• Relative Humidity: (operating) 10% - 80%RH (non-condensing) (non-operating) 5% - 90% RH (non-condensing)
System Requirements
Mac® Requirements:
• OS 8.6 and later with an available USB port or OS 10.2.8 and later via Ethernet for network operation.
PC Requirements:
• Windows ME, Windows XP, Windows 2000 (Home or Professional), Windows Vista and an available USB port or
via Ethernet for network operation.
Two Year Solution Warranty - In addition to NewerTech's two year warranty, the internal hard drive mechanism may be covered by up to an additional three year warranty direct with the drive manufacturer. (80GB to 750GB configured solutions)
Note: Do not disassemble or otherwise open your NewerTech storage solution prior to the conclusion of the NewerTech warranty period. Doing so will void the remainder of the NewerTech warranty.
1. Hard drive access and power.
2. Network status (LINK).
3. 100MBit/s connection.
4. Smart power switch. Turn off miniStack NAS manually, or leave on and it will power up and down in tandem with the computer.
5. Power receptacle.
6. User configurable fan settings.
7. One USB2.0 Uplink ‘B’ port (rear).
8. One RJ-45 10/100Base-TX Auto MDI/MDI-X port.
9. One USB 2.0 High Speed port.
10. Kensington Security Slot.
11. Side vents.
• External 100~240v 50/60Hz UL Listed power adapter
- 3A power supply gives you less stress and clean ample power!
• Ethernet RJ-45 and USB cables.
• Power adapter plus cord, screw package, and driver CD.
• Color product manual.
