This Firmware is for the following
OWC Mercury SSD Models:
  • Extreme Pro 6G
  • Extreme Pro 3G
  • Extreme Pro RE
  • Aura Pro
  • Aura Pro 1.8
  • Aura Pro MBA
  • Electra 3G
  • Electra 6G
Download for Electra 3G/6G and Extreme 6G Firmware
Also available via BitTorrent download. Download the md5 file for this revision. Download for all other OWC 3G SSDs
Download the md5 file for this revision. Not supported:
  • Enterprise Pro 6G
  • Electra MAX
  • Legacy Models
Please read all instructions below carefully before proceeding for information that may affect your specific computer.
It is always highly recommended that you backup your data. Your data must exist in multiple locations to be qualified as having a back up. Anytime a drive is being updated, upgraded or moved, there is a potential for data loss. This update is non-destructive for any SSD already partitioned for NTFS or FAT32 and while OWC has updated several drives with no data loss, we strongly recommended backing up all data on the SSD before performing this update. See the FAQ at the bottom if you are unsure if your drive is currently set for NTFS/FAT32. Instructions to verify your firmware version.

If your OWC SSD Firmware revision contains xxxA12F0 or xxxA13F0, then xxx365A12F0 or xxx365A13F0 is the most up-to-date revision, current as of October 20, 2011.

If your OWC SSD Firmware revision contains xxxABBF0, then 541ABBF0 is the most up-to-date revision, current as of March 5, 2014.
  • Booted into Windows XP/Vista/7/8/8.1 (Boot Camp® or PC)
  • Administrative access in Windows
  • Available internal motherboard SATA port (expansion cards not supported)
  • SSD must either be initialized with an MBR partition table or have a Windows partition applied through Apple's Boot Camp Assistant
  • OWC Mercury 3G or 6G SSD

  1. Back up data to an alternate drive. OWC has updated several drives without data loss, however we strongly recommended backing up all data on the SSD before performing this update
  2. Connect SSD to a native internal SATA port
  3. Boot into Windows XP/Vista/7/8/8.1
  4. All applications should be closed prior to updating the firmware
  5. Launch the OWC Mercury SSD firmware updater application. Upon launch, the Update Tool will automatically scan for connected drives. All discovered drives will be displayed in the drive list with a checkbox. Select the checkbox of the drive you would like to update. Only one drive can be updated/selected at a time
  6. Once the target drive has been selected click the open button (...) and select the MP-5.4.1.ffp file located in the OWC Mercury 6G SSD Firmware Updater folder
  7. Initiate the update by clicking "Update Firmware" A pop-up window will be displayed suggesting back-up of data and reminding that the computer will be restarted after the update. Click "OK" if ready or "Cancel" to stop the update
  8. After your computer restarts, open the OWC Mercury 6G SSD firmware updater application and verify that your Firmware Rev shows 541ABBF0
  1. Back up data to an alternate drive. This update is non-destructive for any SSD already containing an NTFS or FAT32 Partition (Bootcamp automatically does this). OWC has updated several drives without data loss, however we strongly recommended backing up all data on the SSD before performing this update.
  2. Connect SSD to a native internal SATA port.
  3. Boot into Windows XP/Vista/7/8/8.1
  4. All applications should be closed prior to updating the firmware.
  5. Launch the ssdupdate.exe application. Upon launch, the Update Tool will automatically scan for connected drives. All discovered drives would be displayed in the drive list with a checkbox. Select the checkbox of the drive you would like to update. Only one drive can be updated/selected at a time.
  6. Once the target drive has been selected click the open button (...) and select the MP-5.4.1.ffp file located in the OWC SSD Firmware Update Tool folder.
  7. Initiate the download by clicking "Download Firmware to Selected Drive." A pop-up window will be displayed suggesting back up of data and reminding that the computer will be restarted after the update. Click "OK" if ready or "Cancel" to stop the update.
  8. After your computer restarts, open the ssdupdate.exe application and verify that your Firmware Rev shows 541ABBF0.
  No drives are discovered when I run the firmware update tool.
  • The Update Tool requires administrator privileges. No drives will be discovered if administrator privileges are not enabled.
  • If your account does not have administrator privileges enabled, please read the following:
    • Windows XP users: Log into an account with administrator privileges or contact system administrator.
    • Windows Vista/7 users: Right click on the OWC Mercury SSD firmware updater icon and select "Run as administrator."
  • Make sure you are using a native internal SATA port. The updater cannot see SSD drives attached to 3rd party SATA expansion cards or enclosures.
Aura, Mercury Aura, Mercury Electra and Mercury EXTREME are trademarks of New Concepts Development Corporation, registered in the U.S. Patent and Trademark Office. Apple and Boot Camp are trademarks of Apple Inc., registered in the U.S. and other countries. Other marks may be the trademark or registered trademark property of their owners.
