OWC 13-Port Thunderbolt 3 Dock
Used | OWC Tested
Mfr P/N: TB3DK13PSL OWC SKU: OWCTB3DK13PSLU
13 ports, Endless Possibilities
- Easily connect all of your devices
- (2) Thunderbolt 3 (USB-C) ports (Thunderbolt 2/Thunderbolt backward compatible)
- (5) USB 3.1 Gen 1 ports
- Daisy chain 6 Thunderbolt devices
- Connect two 4K displays or one 5K display
- Includes Thunderbolt cable
- 1 Year OWC Limited Warranty
With the 13 ports you need, OWC's new Thunderbolt 3 Dock brings unbelievable connectivity to your laptop through an included Thunderbolt cable, and, delivers charging power to your laptop and other devices, all at the fastest speeds possible.
Thunderbolt 3 Dock delivers more connectivity, more power, and more charging capability than ever before all at the fastest speed available today so all your connected devices perform at their maximum. Drive two 4K displays, connect and charge up to six USB devices, work with legacy FireWire storage, enjoy pristine audio, wired networks, and read SD cards, all with twice the throughput of Thunderbolt 2 and all through a single cable. The possibilities are endless.
Dual Thunderbolt 3 Ports
Delivering the fastest, most versatile connection currently available up to 40Gb/s.
Five USB 3.1 Gen 1 Ports
The most ubiquitous interface on the planet delivers 5Gb/s data speed, as well as high power to your devices.
SD Card Reader
With a front-facing SD card reader, easily transfer every captured moment. Copy photos and movies from your media cards direct to your Mac.
Expanded Analog Audio
Seamlessly connect external speakers and other audio equipment, listen to your favorite music, create podcasts and more with added audio-in and headphone ports.
Gigabit Ethernet
Gigabit Ethernet brings access to high-speed, reliable wired networks back to your Mac.
FireWire 800
Connect your favorite legacy devices directly to your new workflow hub.
View your world
Because Thunderbolt 3 delivers phenomenal bandwidth up to 40Gb/s, Thunderbolt 3 Dock can be the foundation of your perfect custom display setup. Add two ultra HD 4K displays, or a combination of 4K, HD and other displays with the mini DisplayPort port and additional Thunderbolt 3 port.
Connect with your workflow
If you're a pro working in the creative industries, you probably have a unique workflow, complete with specialized and legacy ports like FireWire and optical audio. The OWC Thunderbolt 3 Dock supports FW800 and S/PDIF digital audio, as well as an SD card reader and analog stereo audio to integrate and improve the workflow you already know.
Quality and support you can trust
OWC is proud to provide outstanding support and warranty coverage to our customers delivering the peace of mind offered by long warranty periods. OWC's industry leading coverage is a testament to the reliability of our solutions. All OWC connectivity products are engineered to demanding quality standards in order to deliver the most reliable performance available on the market.
- Thunderbolt 2/Thunderbolt compatibility requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and a Thunderbolt 2 cable. This configuration provides data transfer at Thunderbolt 2 speeds (up to 20Gb/s) but does not support notebook charging.
Includes
Back to top
- (1) OWC Thunderbolt 3 Dock
- (1) 0.5M (18") Thunderbolt cable
- (1) External Power Supply and Power Cable
- (1) Quick Start Guide for OWC Thunderbolt 3 Dock
- (1) User Guide for OWC Thunderbolt 3 Dock
- (1) OWC Dock Ejector for Mac and Windows (software download)
- (1) User Guide for OWC Dock Ejector
- 1 Year OWC Limited Warranty
Specs
Back to top
Device Ports
- (2) Thunderbolt 2 Ports
- (5) USB 3.2 Gen 1 Type-A Ports up to 600MB/s
- (1) FireWire 800 Port
- (1) Mini DisplayPort Port
- (1) Gigabit Ethernet (GbE) RJ-45 Port
- (1) 3.5mm Mono Audio Input Port
- (1) 3.5mm Stereo Audio Output Port
Power Delivery
- Provides up to 60W of Power Delivery via host port.
Additional Ports
- (1) S/PDIF digital audio port (Output only)
Display Support
- Up to one 5K display @ 60Hz,
- or two 4K displays @ 60Hz
Display Support by Port
- Thunderbolt 3: Up to 5K @ 60Hz via a native Thunderbolt 3 display or 4K @ 60Hz via a Thunderbolt display or a USB-C display adapter
- Mini DisplayPort 1.2: Up to 4K @ 60Hz
Ethernet Speeds (RJ-45)
- 1Gb/s "Gigabit" (1000BASE-T)
- 100Mb/s (100BASE-T)
- 10Mb/s (10BASE-T)
Host Interface Requirements
- Mac or PC with a Thunderbolt 3 port or later
- Mac with Thunderbolt 2/Thunderbolt port (requires adapter)
Mac OS Compatibility
- macOS 10.12 Sierra
- macOS 10.13 High Sierra
- macOS 10.14 Mojave
- macOS 10.15 Catalina
- macOS 11.x Big Sur
- macOS 12.x Monterey
- macOS 13.x Ventura
PC OS Compatibility
- Windows 10 32-bit Edition
- Windows 10 64-bit Edition
- Windows Server 2016
- Windows 11
Driver Required
- Download Driver
- High-power USB support is required for compatibility with the Apple SuperDrive and Apple USB keyboard, and is required to enable high-speed charging for Apple iPads, iPhones and other higher-power capable devices. To enable high-power USB support please download the appropriate app and driver bundle.
Other Requirements
- Requires macOS 10.12.2 or later.
- Thunderbolt 2/Thunderbolt compatibility requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and a Thunderbolt 2 cable. This configuration provides data transfer at Thunderbolt 2 speeds (up to 20Gb/s) but does not support notebook charging.
External Power Adapter
- Yes
Power Supply
- External UL-listed universal auto-switching power supply
- Need an additional power supply? Secondary/replacement power supplies are also available.
AC Input
- 100-240V, 50-60Hz, 2.0A
DC Output
- +12V, 6A
Wattage
- 72W
Security Slot
- No
Housing Color
- Chassis: Silver
- Covers: Black
Housing Material
- Chassis: Aluminum
- Covers: Polycarbonate
Dimensions
- Height: 2.5 cm (1.0 in)
- Length: 9.0 cm (3.5 in)
- Width: 23.0 cm (9.1 in)
Weight
- 380.0 g (0.84 lbs)
Certifications
- CE
- FCC
RoHS Compliant
- Yes
Country of Origin
- China
TAA Compliance
- No
Altitude
- Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft)
- Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)
- Dual displays require a native Thunderbolt 3 display or the appropriate Thunderbolt 3 adapter
- Display resolutions and refresh rates will vary depending upon hardware, connections, and OS in use
- Does not support display-chains via MST (Multi-Stream Transport)
- Dual display support, including available resolution and refresh rates, is dependent on host hardware and drivers.
- Apple silicon M1/M2/M3 Pro, M1/M2/M3 Max, and M1/M2 Ultra Mac models, Apple Intel-based Mac models, and Thunderbolt 4 PCs can support up to two displays at up to 4K @ 60Hz via Thunderbolt.
- Apple silicon M1/M2/M3 Mac models can support one external display up to 4K @ 60Hz via Thunderbolt. - The following Apple silicon M1/M2/M3 Mac models support a single display over a Thunderbolt port:
- MacBook Pro (14-inch, M3, 2023)
- MacBook Pro (13-inch, M1, 2020) - MacBookPro17,1
- MacBook Pro (13-inch, M2, 2022) - Mac14,7
- MacBook Air (M1, 2020) - MacBookAir10,1
- MacBook Air (M2, 2022) - Mac14,2
- Mac mini (M1, 2020) - Macmini9,1 - The following Mac models provide only partial support for DisplayPort 1.4, including limiting resolution to 5K or 6K at 60Hz. Please review Apple's display specifications for your specific Mac to determine the maximum supported resolution and color depth:
- MacBook Pro (15-inch, 2018) - MacBookPro15,1
- MacBook Pro (13-inch, 2018, Four Thunderbolt 3 ports) - MacBookPro15,2
- MacBook Pro (13-inch, 2019, Four Thunderbolt 3 ports) - MacBookPro15,2
- MacBook Pro (15-inch, 2019) - MacBookPro15,1 and MacBookPro15,3
- MacBook Pro (13-inch, 2019, Two Thunderbolt 3 ports) - MacBookPro15,4
- MacBook Pro (16-inch, 2019) - MacBookPro16,1 and MacBookPro16,4
- MacBook Pro (13-inch, 2020, Four Thunderbolt 3 ports) - MacBookPro16,2
- MacBook Pro (13-inch, 2020, Two Thunderbolt 3 ports) - MacBookPro16,3
- MacBook Air (Retina, 13-inch, 2018) - MacBookAir8,1
- MacBook Air (Retina, 13-inch, 2019) - MacBookAir8,2
- MacBook Air (Retina, 13-inch, 2020) - MacBookAir9,1
- iMac (Retina 5K, 27-inch, 2019) - iMac19,1
- iMac (Retina 4K, 21.5-inch, 2019) - iMac19,2
- iMac (Retina 5K, 27-inch, 2020) - iMac20,1 and iMac20,2
- Mac mini (2018) - Macmini8,1
- Mac Pro (2019) - MacPro7,1
- Mac Pro (Rack, 2019) - MacPro7,1 - Dual display configurations are possible with the Mac mini via the additional built-in HDMI 2.0 port.
- Connected drives may display the wrong desktop icon and not be ejectable through Dock Ejector when connected over the (2) rear-right-side USB 3.1 Gen 1 Type-A ports.
- OWC Dock Ejector is developed for OWC products. Third party hubs and docks are not supported.
- Recorded sound input playback will be quiet. Adjusting the input volume in System Preferences does not improve the softness of the recording playback. Connecting the desired input directly into the computer system will improve the recorded sound input.
