1.0TB OWC Mercury Electra 3G
DIY Optical Drive to Solid-State Drive Upgrade Kit for iMac (Late 2009 - Mid 2011)
Mfr P/N: DDIMSSD1TB OWC SKU: OWCDDIMSSD1TB
$90.99 off - *NOW* Get Parallels Desktop Pro Edition - Windows/Multi OS Compatibility software for Mac - Only $29.00 with select OWC SSDs, HDDs, Memory, External Storage, and Optical Drives! (Limit 3 rebates, 1 rebate per qualifying item)
Must purchase with: Parallels Desktop Pro Edition for Mac - 1 Year License. SPECIAL PURCHASE
Everything you need – all in one kit!
- Replace the internal optical drive in your iMac (2009 - 2011) with the power and reliability of an OWC Solid-State Drive
- Easily expand your internal storage
- Durable toolkit makes installation easy
- Offers custom configuration options for the added drive
- No drivers or extra software required for operation
- 1 Year OWC Limited Warranty
Just a few of the configuration options you can enjoy with Data Doubler:
- Combining a new drive with the existing internal drive for one larger volume (SPAN).
- Combining a new matching drive with existing internal for high-performance RAID-0 Stripe volume.
- Configuring a new drive as a Time Machine backup drive.
- Formatting one drive for the Mac OS and the other dedicated for Windows.
- Professional installation of Data Doubler into an iMac is highly recommended due to degree of installation difficulty. OWC assumes no responsibility for damage that may occur during the install.
Includes
Back to top
- (1) OWC Mercury Electra 3G Solid-State Drive
- (1) OWC Data Doubler Optical Bay Mounting Solution
- (2) OWC 2.25-inch Suction Cup
- (1) Torx T10 Driver
- (1) Torx T8 Driver
- (1) Torx T6 Driver
- (1) Phillips #00 Driver
- (1) Nylon Pry Tool (Spudger)
- (1) OWC Blue Microfiber Screen Cleaning Cloth
- 1 Year OWC Limited Warranty
Specs
Back to top
1.0TB OWC Mercury Electra 3G 2.5-inch 7mm SATA 3.0Gb/s Solid-State Drive
- 1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.
- Temperature reporting is currently an unsupported feature because due to the operating characteristics of SSDs, it is highly unlikely one would ever exceed an OWC Mercury SSD's stated operating temperature ceiling of 158F/70C. However, we are looking into supporting this feature in the future via a firmware update. Firmware updates can be found here: http://eshop.macsales.com/tech_center/OWC/SSD.
Capacity
- 1000GB Useable Capacity
- Total Flash Memory Components: 1064GB
- 64GB Allocated to real-time data redundancy and error correction
Formatted Capacity
- 931GiB
Drive Format
- Unformatted (Instructions on formatting here)
Controller
- Silicon Motion SM2246EN Series Processor with 7% over-provisioning
NAND Flash Components
- Tier 1 Asynchronous Multi-Level Cell (MLC) NAND Flash
S.M.A.R.T. Attributes
- Standard attributes supported
Native Command Queuing (NCQ)
- Up to 32 simultaneous commands
RAID Support
- Yes
Form Factor
- 2.5-inch 7mm
Drive Interface
- SATA 3.0 Gb/s
Random 4K Read
- Up to 60,000 IOPS
Random 4K Write
- Up to 60,000 IOPS
Sustained Read (3Gb/s)
- Up to 250 MB/s
Sustained Write (3Gb/s)
- Up to 230 MB/s
Read Latency (Max)
- 100 µs
Nonrecoverable Read Errors
- 1 per 1016 bits read
TRIM Support
- Yes
Error Correction
- Built-in ECC
Security
- Chip Based Data Encryption: 256-bit AES-compliant
Read Mode (Max)
- Up to 2 Watts
Write Mode (Max)
- Up to 2 Watts
Idle Mode (Max)
- Up to 0.7 Watts
Dimensions
- Height: 0.7 cm (0.3 in)
- Length: 10.0 cm (3.9 in)
- Width: 7.0 cm (2.8 in)
Weight
- 77.0 g (0.17 lbs)
RoHS Compliant
- Yes
Ambient Temperature
- Operating: 32°F to 158°F (0°C to 70°C)
- Non-Operating: -40°F to 185°F (-40°C to 85°C)
Altitude
- Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft)
- Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)
Idle (Typical)
- 0.0 bels
Seek (Typical)
- 0.0 bels
OWC Microfiber Wipe
Color
- Blue
Dimensions
- Length: 30.5 cm (12.0 in)
- Width: 30.5 cm (12.0 in)
