DIY Bundle

1.0TB OWC 3G SSD
and HDD Kit for Late 2009 - 2010 iMacs

Mac

Mercury Electra SSD and iMac HDD Kit

Upgrade with Confidence!

The complete solution for your 2009 - 2010 iMac

Experience the extreme performance of an OWC SSD upgrade with this easy DIY SSD and hard drive replacement kit. Add an SSD to your hard drive equipped iMac to experience faster booting, near instant application launches and lightning fast data transfer speeds.

Fast and reliable solid-state storage

With incredible sustained data speeds, up to 100X greater data protection than enterprise class Hard Disk Drives, and RAISE technology for RAID like data protection and reliability, the OWC Mercury 3G SSD line delivers unbeatable performance, that's backed by an incredible OWC SSD Limited Warranty.

Upgrade Your iMac with Confidence.

OWC's in-line solution is the only hardware digital thermal sensor on the market allowing a third-party SATA drive to be installed in your iMac. A convenient, plug-and-play cable, the In-line Digital Thermal Sensor eliminates fan noise and maintains proper system fan control through the iMac's System Management Controller. This innovative device is designed specifically for the iMac, requires no software hacks and ensures compatibility with Apple's built-in diagnostic processes.

Highlights

Add a high-performance OWC 3G SSD to your iMac.
No software hacks required.
Backed by free DIY install videos and expert support.

Maintains highest performance while offering ultimate convenience

The NewerTech AdaptaDrive has been benchmark test proven to deliver the same data transfer rates as is experienced when a drive is connected directly to the SATA data bus. The AdaptaDrive doesn't create a bottleneck or any performance throttling...it delivers pure data pass-through performance and drive use convenience from any 2.5" SATA 1.5Gb/s, 3Gb/s, or 3Gb/s hard drive or SSD.

Please note, that before attempting to perform this installation, it is recommended you watch the associated instructional video in its entirety to determine your ability to perform this complex procedure. OWC assumes no responsibility for damage that may occur during the install.

1.0TB Mercury Electra 3G SSD Specifications:

Specifications

Controller

Silicon Motion SM2246EN Series with 7% Over Provisioning firmware set

NAND

Tier 1 Asynchronous MLC NAND Flash

Form Factor

Standard 7mm 2.5"

Interface

SATA 3Gb/s & 1.5Gb/s supported, SATA 2.0 Compliant

Capacity¹

960GB useable capacity
Total Flash Memory Components – 1024GB
64GB allocated to real-time data redundancy & error correction

Formatted Capacity²

930GiB

RAID Support

Qualified for single drive and multiple drive production workstation RAID 0/1/10/0+1 and SPAN usage.

SMART Attributes

Standard⁴

Native Command Queuing

up to 32 commands

Manufacturer Model Number

OWCSSD7E3G960

RoHS Compliant

Yes

Format

Unformatted (Instructions on formatting here)

Physical

Height (max)

7mm (0.276″)

OWC 7mm – 9.5mm Adapter

1 included (buy additional)

Width (max)

70.06mm (2.758″)

Length (max)

100.12mm (3.941″)

Weight

77 grams +/- 2 grams
0.170 lbs +/- 2.71 oz

Reliability³

Data Reliability

Built-in BCH ECC: Up to 66 bits correctable per 1024 bytes

Security

Chip Based Data Encryption: 256-bit AES-compliant

TRIM Support

Yes

Nonrecoverable Read Errors

Less than 1 sector per 10¹⁶ bits read

Warranty

3 Year OWC SSD Limited Warranty
(Standard return policy applies.)

Performance

Sustained
Reads 3Gb/s (up to)

250MB/s

Sustained
Writes 3Gb/s (up to)

230MB/s

Power

Active

Less than 2000mW (2.0W) expected maximum draw

Idle

Less than 700mW (0.7W)

Environmental (Operating)

Temperature (°F)

32°F to 158°F

Temperature (°C)

0°C to 70°C

Environmental (Non-Operating)

Temperature (°F)

-40°F to 185°F

Temperature (°C)

-40°C to 85°C

Acoustics

Idle (Typical)

0.0 bels

Seek (Typical)

0.0 bels

1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.
In terms of standard gigabytes, 1GiB ≈ 1.074GB and refers to the actual formatted capacity of shown under Mac OS 10.5 or earlier and Microsoft Windows OS.
Specific application environments such as temperature and duty cycle will affect the overall reliability.
Temperature reporting is currently an unsupported feature because due to the operating characteristics of SSDs, it is highly unlikely one would ever exceed an OWC Mercury SSD's stated operating temperature ceiling of 158F/70C. However, we are looking into supporting this feature in the future via a firmware update. Firmware updates can be found here: http://eshop.macsales.com/tech_center/OWC/SSD.

AdaptaDrive Specifications:

NewerTech Part Number

ADPTADRV

Drive Inteface

Fully SATA Revision 3.0 (3Gb/s) compatible
SATA Revision 2.0 (3Gb/s) and 1.0 (1.5Gb/s) compatible

Drive Supported

(1) 2.5" SATA 3Gb/s drive

Material

Black painted Aluminum

Dimensions

Height: 0.4 in (1.0 cm)
Width: 4.0 in (10.2 cm)
Length: 5.8 in (14.7 cm)

Weight (Without Drives

3.5 oz (99.2 g)

Manufacturer provided specifications for Other World Computing p/n KITIM09HE1TB

Gallery

27" iMac (2010) Install Video

21.5" iMac (2010) Install Video

27" iMac (2009) Install Video

21.5" iMac (2009) Install Video

This product is compatible with... Learn how to find your Mac's model ID

iMac (27-inch Mid 2010)

(July 2010)

Model ID: iMac11,3

3.2GHz i3, 2.8GHz i5, 3.6GHz i5, 2.93GHz i7

Detailed specs

Install Videos

iMac (21.5-inch Mid 2010)

(July 2010)

Model ID: iMac11,2

3.06GHz i3, 3.2GHz i3, 3.6GHz i5

Detailed specs

Install Videos

iMac (27-inch Mid 2009)

(October 2009)

Model ID: iMac11,1

2.66GHz i5, 2.8GHz i7

Detailed specs

Install Videos

iMac (27-inch Mid 2009)

(October 2009)

Model ID: iMac10,1

3.06GHz, 3.33GHz

Detailed specs

Install Videos

iMac (21.5-inch Late 2009)

(October 2009)

Model ID: iMac10,1

3.06GHz, 3.33GHz

Detailed specs

Install Videos

Includes

(1) OWC Mercury 3G SSD
(1) AdaptaDrive 2.5" to 3.5" Drive Converter Bracket

(4) 2.5" drive to bracket mounting screws
(4) Bracket to 3.5" drive bay mounting screws
AdaptaDrive Assembly Manual & User Guide

(1) In-line Digital Thermal Sensor Cable
(2) NewerTech 2.25" Suction Cup
(1) Torx T10s driver
(1) Torx T8s driver
(1) NewerTech pry tool
(1) Microfiber scratch-free cloth

NOTE: This kit contains consumable and/or one time use components and therefore is non-refundable if opened. If you have any concerns about your ability to perform the upgrade, you can return the unopened kit for a refund.

Warranty

The best warranty is one you never have to use - but should the need occur - we're proud to provide a superior level of support and service coverage to our customers.

3 Year OWC SSD Limited Warranty on the OWC Mercury Electra 3G SSD

1 Year OWC Brand Standard Limited Warranty on the OWC In-line Thermal Sensor cable

5 Year NewerTech Product Limited Warranty on the NewerTech AdaptaDrive

Even when not used, we understand the peace of mind afforded by a longer warranty period. OWC's industry leading coverage is a testament to our confidence in the reliability of the solutions that we offer. OWC solutions are engineered to demanding quality standards in order to deliver the most reliable, highest performance available on the market in each storage category.

Customer Ratings

Write a Review 5 / 5 6 out of 6 (100%) reviewers would recommend this product

Verified Buyer

Reviewer: RehabAddict Location: Wisconsin Age: 45-54 Experience Level: Home User Owned Product: 1-3 months

Rating: 5/5 Works as advertised August 6, 2016 Purchased the DIY kit for the 1.0T SSD to replace the 1.0T factory HDD on my 2009 27" model 11.1 iMac. The kit contained all necessary equipment to do the job. Followed the instructional video and completed the replacement without hurrying in about an hour. Also updated the 8G factory RAM to 32G with the OWC 4x8G RAM kit. Reinstalled the OS without difficulty. The iMac is like a completely new machine now. Boots up so much faster and programs open nearly instantly. Have been up and running for nearly 4 months now without any issues. Would highly recommend these upgrades if you are looking to rehabilitate your older iMac and avoid spending the $ for an entirely new one.

I would recommend this item to a friend! Customer Videos:

Verified Buyer Top 100 Contributor

Reviewer: Anonymous Location: Rochester, MI Age: 45-54 Experience Level: Power User Owned Product: 1-3 months

Rating: 5/5 Temp sensor cable works great July 31, 2016 without a temp sensor, my fan sounded like a hair dryer. I never knew the fan could even blow that hard. I really did not want manual control, the OWC solution works great.

I would recommend this item to a friend!

Verified Buyer

Reviewer: Anonymous Location: Sydney Australoa Age: Over 65 Experience Level: Home User Owned Product: over 6 months

Rating: 5/5 SSD kit for late 2009 iMac27" July 20, 2016 Everything went swimmingly. The installation video was very clear and easy to follow. The installation tools were perfect. The iMac now rocks! All in all a good experience. I am happy. Thank you OWC

I would recommend this item to a friend!

Verified Buyer

Reviewer: Anonymous Location: Queensland, Australia Age: 45-54 Experience Level: IT Professional Owned Product: 1-3 months

Rating: 5/5 Brings new life and snapiness to older Macs, well worth it! May 21, 2016 Hello, long time listener, first time caller.

I installed this upgrade in to a 2010 era i7 iMac and was amazed with how it made the Mac run like a gazelle on Red Bull with a few espresso chasers.

The chassis and the thermal sensor substitute took this upgrade a step above similar offerings. No running-flat-out fans, no instability, just blistering fast performance.

MacSales' video guides are brilliant! Without them I would never have had the confidence to perform this upgrade on an iMac. With the video clips showing every step and tip in clear detail - and treating the process like an astronaut EVA, ie. take your time, be meticulous and no-one/nothing dies - the upgrade went perfectly.

I'd also like to thank the MacSales support staff (looking at you, Randy G.!) for being very helpful when I had the smallest of queries about part of the upgrade process.

If you're thinking about this upgrade for your ageing Mac, do consider it; it made a world of difference to one of our older Macs. We also have a 2013 iMac of similar spec with a Fusion drive and I think this upgrade made the older Mac able to snap at its heels.

cheers, and thanks again, MacSales!

I would recommend this item to a friend!

Verified Buyer

Reviewer: Anonymous Location: Auburn, CA Age: Over 65 Experience Level: Home User Owned Product: 1-3 months

Rating: 5/5 Outstanding product May 14, 2016 My increasingly slow mid-2010 iMac needed an upgrade so I purchased the OWC 1Tb SSD drive to replace my internal stock hard-drive. The product is packaged with everything anyone needs to do the upgrade, and with the online video instruction the installation was extremely smooth. Formatting and backup installation of the OS and all my files were seamless. There is virtually no sound from the SSD and it has made my iMac like new. The speed with which applications, files and processes open is insane. This is a wonderful product.

I would recommend this item to a friend!

Verified Buyer

Reviewer: Anonymous Location: Texas Age: 35-44 Experience Level: Home User Owned Product: less than a month

Rating: 5/5 Great Replacement! April 19, 2016 I've only had this drive in the computer for about 24 hours; however, I can say that the speed of my 2010 27" iMac has increased tenfold. While the drive that I removed was the original 1TB and had well over 500 bad sectors and therefore extremely slow, it is undoubtedly much faster than it has ever been. Opening apps is faster, browsing the Internet is faster, startup is faster. I have absolutely no regrets about this purchase and with it being from OWC and having specific items needed to make it work, i.e. thermal sensor, included when buying the installation kit makes this choice is a no-brainer.

I would recommend this item to a friend!
