Name: 18.0TB OWC Node Titan SE Thunderbolt NVMe RAID External Storage Solution with SoftRAID
Brand: OWC
SKU: OWCNPTNT3SE018
Price: 2999.99 USD
Availability: InStock

18.0TB OWC Node Titan SE

$2,999.99 Order Now: Only 1 in stock, more coming soon.

Professional Thunderbolt Portable NVMe SSD RAID

Thunderbolt Eclipsing Performance: up to 2919MB/s speeds to completely obliterate the Thunderbolt threshold¹
Massive Space: nine NVMe SSD blades combine to deliver jaw-dropping storage capacity up to 72TB
Customizable RAID: your choice of RAID 0/1/4/5/1+0 (10) for speed, data protection, or both
Includes SoftRAID: robust software for creating, monitoring, and managing advanced RAID sets
Powerfully Convenient: up to 85W for notebook charging and built-in power supply eliminates separate bulky power adapters
Pre-Tested and Certified: full burn-in for assured performance and reliability
Grab & Go: retractable handle for easy portability
Shippable: Custom ballistic hard-shell travel case lets you send the solution anywhere
3 Year OWC Limited Warranty

Be the first

In Stock: Ships Same Day!

Free Shipping

$2,999.99

Order Now: Only 1 in stock, more coming soon.

Add to Cart

scroll for more options >

Direct from the creative minds of the “Skunk Works” technologists here at OWC is another breakthrough innovation to solve your biggest challenge: how to get fast and massive external storage capacity that you can conveniently move around on-location, in the editing studio, or even ship to a post facility. Challenge accepted…and solved with the Node Titan SE. This Special Edition storage solution is the world’s highest capacity portable NVMe SSD RAID and it will completely transform how you utilize your Thunderbolt equipped Mac or Windows PC computer.

Up to 72TB of usable storage in RAID 0 with speeds up to 2926MB/s. A rugged commercial quality electrogalvanized steel case with a recessed handle to withstand demanding mobile use. A ballistic travel case for protective shipping. Node Titan SE is like our world-famous ThunderBlade pumped up to the max muscle on steroids!

Max Your Mac Studio

For all its wonderous capabilities, the Mac Studio has a couple of shortcomings. The internal storage is limited to a max of 8TB as a factory option and isn’t upgradeable. There aren’t any PCIe expansion slots to add a storage card. Whatcha gonna do when your projects’ capacity requirements come for you? Bad Boys Bad Boys (yeah…we like our reggae and COPS) like you need the biggest baddest capacity solution in the land to get the max usefulness from your Mac Studio.

Designed For Those That Need More

Our team is filled with creatives highly experienced in all phases of the video production world. We get your need for more speed and capacity when it comes to everything from backup to editing. Node Titan SE is a Simply Elegant portable problem-solver for pros like you that need more from their storage:

DITs and productions needing a shuttle drive that can be easily shipped while also offering performance and reliability.
Professional video editors wanting a seamless editing experience with a drive capable of storing up to 72TB of data to have all the files centralized and easily accessible while editing.
Creative professionals working with cutting edge workflows such as VFX, multicam 4-6K, 8-12K RAW video, 360 VR content looking for ultra-high-capacity storage with the best possible performance when using an external storage solution.

The RAID 5 Problem Solver

Using RAID 5 in the past meant giving up precious capacity and taking a big hit on performance. Node Titan SE solves that problem by offering up to a massive 64TB of useable storage while nearly maxing out Thunderbolt 40Gb/s limits with speeds up to 2477MB/s. Now you can streamline ingestion and backup times on set, edit ultra-high-res multi-cam sequences, and adhere to mandatory requirements (the 3-2-1 Principle) when producing content for large studios such as Netflix.

Grab n' Go Flexibility

Transcoding, offloading, backing up, or editing video on-the-go has never been easier. The Node Titan SE features a commercial quality electrogalvanized steel case with a retractable carrying handle to take powerful video production capabilities along safely and easily wherever you roam.

Powerfully Unlimited

You can work without limits when you add the Node Titan SE to your workflow. There’s a built-in power supply to keep your workspace free from the bulk and clutter of a power brick. If you’re using a notebook, you can charge its battery while pushing your creativity and machine to the limit. No more separate power adapter needed... just connect the Node Titan’s 85W Thunderbolt upstream port to your notebook via the included Thunderbolt cable and you’re set.

The Most Powerful RAID Tool on the Planet.

SoftRAID is the world’s fastest and most flexible application to configure, maintain, and protect your RAID volumes on Mac and PC. OWC enclosures include 3 Years of SoftRAID Premium.

High-Performance RAID 0/1/4/5/1+0 (10) volumes
Predictive Health Monitoring proactively notifies of Volume and Disk issues well before failure — provided on your computer and remotely
35+ Years of Experience of Pro Support to provide peace-of-mind with setup help, ongoing questions, or urgent disk issues
And many more unique features.
Learn more about SoftRAID

SoftRAID works with macOS 10.14+, Windows 10+, and Windows Server 2019/2022. M1 Macs require macOS 11.3 or later. SoftRAID is licensed per computer.

OWC Thunderbolt Cable Included

OWC Node Titan SE solutions come with a certified 0.7M OWC Thunderbolt (USB-C) Cable. But if your workflow demands a different length to make the connection, OWC Thunderbolt (USB-C) Cables are the perfect choice.

Thunderbolt Made Easy

We make it easy to choose the right gear. Our Thunderbolt Certified products offer the same performance and functionality whether they are Thunderbolt 3 or Thunderbolt 4. And if you’re rocking a beloved Thunderbolt 2 machine, we offer a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter so you can plug into our universe of award-winning solutions. No hassles, no confusion. That’s the OWC Difference.

Apple Mac models with Thunderbolt 2/Thunderbolt ports can be connected using a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter and a Thunderbolt 2 cable (not included). This configuration provides data transfer at up to 20Gb/s but does not support notebook charging.

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2021, MacBookPro18,1) with Apple M1 Pro processor and 16GB RAM. Performance will vary depending on a variety of factors including specific file size and format, CPU speed, RAID setting, software, and other features/factors.
RAID 4/1+0 (10) is available for Mac only at this time.

Includes

(1) OWC Node Titan SE
(1) 0.7M (28") Thunderbolt Cable
(1) Power Cable
(1) Ballistic Hard-Shell Travel Case
(1) Support Manual for OWC Node Titan SE
(1) 3 Years of SoftRAID Premium Access (License located on device)
(1) Quick Start Guide for OWC SoftRAID (Digital)
3 Year OWC Limited Warranty

Specs

Total Capacity

18.0TB

Drive Mechanism

(9) 2.0TB OWC Aura Ultra IV PCIe 4.0 NVMe M.2 SSD
*OWC reserves the right to replace or upgrade to equivalent or better components.

Plug and Play

Hot Plug Support

Boot Support

Mac only. Boot volume must be independent from RAID volume.

Drive Format

Formatted as 9 disk RAID 0 for SoftRAID. If you are using the OWC Node Titan SE with a Windows PC, the pre-installed drives need to be reconfigured before the device can be used. Please consult the Mac to Windows – SoftRAID Volume Conversation guide by visiting go.owc.com/softraid/convert-ntfs.

Storage Interface

M.2 NVMe (PCIe 3.0)

RAID Capable

Default RAID Level

RAID 0

RAID Levels Supported

RAID 0
RAID 1
RAID 4
RAID 5
RAID 10

RAID Features

Software RAID

Device Ports

(1) Host Port - Thunderbolt 3 (USB-C) up to 40Gb/s (5000MB/s)

Power Delivery

One Thunderbolt 3 port with 85W power delivery

Data Transfer Rate (Maximum)

Thunderbolt 3 : Up to 40Gb/s (or 5000MB/s)

Benchmark Speed, Read (Max)

Up to 2919 MB/s

Benchmark Speed, Write (Max)

Up to 2830 MB/s

Chipset / Controller

Thunderbolt 3: Intel JHL7440

Host Interface Requirements

Thunderbolt (USB-C) port (backward compatible with Thunderbolt 2/Thunderbolt¹)

Mac OS Compatibility

macOS 10.14 Mojave
macOS 10.15 Catalina
macOS 11.x Big Sur
macOS 12.x Monterey
macOS 13.x Ventura
macOS 14.x Sonoma
macOS 15.x Sequoia

PC OS Compatibility

Windows 10 64-bit Edition
Windows 11

Driver Required

SoftRAID Only
SoftRAID automatically checks for the latest driver. Launch the app and if displayed, follow prompts to update driver.

Other Requirements

SoftRAID works with macOS 10.14 or later and Windows 10 or later. SoftRAID is licensed per computer. The SoftRAID serial number will work with both Mac and Windows but can only be active on one computer at a time. Additional seats can be purchased. RAID 4/1+0 (10) are currently Mac only at this time.

External Power Adapter

Power Supply

UL-listed power supply

AC Input

100-240V, 50-60Hz, 10.0A (@100V) | 5.0A (@220V)

DC Output

+12V, 54A

Wattage

650W

Security Slot

Housing Color

Space Gray

Housing Material

Aluminum

Dimensions

Height: 26.6 cm (10.5 in)
Length: 35.7 cm (14.1 in)
Width: 13.5 cm (5.3 in)

Weight

3.5 kg (7.72 lbs)

Certifications

CE
FCC
RoHS
VCCI
RCM
BSMI

Ambient Temperature

Operating: 50°F to 95°F (10°C to 35°C)
Non-Operating: -40°F to 149°F (-40°C to 65°C)

Altitude

Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft)
Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)

Humidity

Operating: 8% to 90% non-condensing
Non-Operating: 5% to 95% non-condensing

Noise

0.0dB

Thunderbolt 2/Thunderbolt compatibility requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and a Thunderbolt 2 cable (not included). This configuration provides data transfer at up to 20Gb/s but does not support notebook charging.
RAID 4/1+0 (10) are Mac only at this time.
SoftRAID works with macOS 10.14+, Windows 10+, and Windows Server 2019/2022. M1 Macs require macOS 11.3 or later.
SoftRAID is licensed per computer.

Benchmarks

There are many attributes that define “The OWC Difference.” By listing real-world performance tests of OWC solutions, we’re confident you’ll be completely satisfied with your technology investment.

macOS RAID 0 Test Results

Blackmagic Disk Speed Test - Intel

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2019, MacBookPro16,1) with 2.4GHz processor and 64GB RAM

Blackmagic Disk Speed Test - Apple silicon

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2021, MacBookPro18,1) with Apple M1 Pro processor and 16GB RAM

AJA System Test - 8K - Intel

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2019, MacBookPro16,1) with 2.4GHz processor and 64GB RAM

AJA System Test - 8K - Apple silicon

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2021, MacBookPro18,1) with Apple M1 Pro processor and 16GB RAM

AJA System Test - 4K - Intel

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2019, MacBookPro16,1) with 2.4GHz processor and 64GB RAM

AJA System Test - 4K - Apple silicon

Thunderbolt 3

Benchmark for 9x 2TB NVMe M.2 SSDs in a NodeTitan in RAID 0 (OWCS3DIGP4XT20) MacBook Pro (16-inch, 2021, MacBookPro18,1) with Apple M1 Pro processor and 16GB RAM
