Name: 120GB OWC Mercury Extreme Pro 6G 2.5-inch 7mm SATA 6.0Gb/s Solid-State Drive
Brand: OWC
SKU: OWCSSD7P6G120
Rating: 4.92 (229 reviews)

120GB OWC Mercury Extreme Pro 6G

We're sorry, but this item is no longer for sale. However, there may be more Internal Hard Drives & SSDs items available.

We recommend 240GB OWC Mercury Extreme Pro 6G 2.5-inch 7mm SATA 6.0Gb/s Solid-State Drive (Mfr P/N: S3D7P6G240) from OWC for $49.99 as a suitable alternative.

High-Performance Storage for Notebook and Desktop Computers.

One of the fastest Internal SATA 2.5? SSDs available.
5 Year OWC Limited Warranty

Reviews (229)

scroll for more options >

High Performance Internal Storage

This internal 2.5" SATA SSD uses the latest SandForce 2281 Processor and DuraClass™ technology to deliver the highest transfer speed, endurance, and performance available today.

High Reliability & Protection

With sustained reads up to 559MB/s and writes up to 527MB/s, up to 100X greater data protection than enterprise class Hard Disk Drives, and RAISE technology for RAID like data protection and reliability, the OWC Mercury Extreme SSD line delivers unbeatable performance.

Includes 7 mm to 9.5 mm Adapter / Spacer

Replace your conventional hard drive with a reliable solid state drive. Unlike traditional hard disk drives, OWC solid state drives have no moving parts, resulting in a quiet, cool, highly rugged storage solution that also offers faster system responsiveness. OWC SSDs allocate some of the drive capacity for RAISE, to provide real time data redundancy, ECC Error Correction, and reserve cell space. Attach this adapter to the top of any 7mm, 2.5-inch drive for installations that require a 9.5mm drive height for proper use, whether you need a 9.5mm drive height for a dock, camera, server, device, PC, or external drive. This adapter is not needed for 2.5-inch drive installations that use the standard side or bottom mounting positions to secure the drive in place, and is not needed for any installation of a 7mm drive in Apple Macintosh computers.

Example:

A 240GB OWC Mercury Extreme Pro SSD is actually a 256GB drive with 7% of the drive's capacity allocated for data management. This management maintains the drive's high-performance and high reliability levels. Unlike many SSDs on the market today, the Mercury Pro family uses advanced DuraWrite™ wear-leveling and block management technologies to keep Read/Write performance at peak, while others see performance fall.

Includes

(1) OWC Mercury Extreme Pro 6G Solid-State Drive
(1) 7 mm - 9.5 mm Adapter
5 Year OWC Limited Warranty

Specs

Total Capacity

120GB Useable Capacity
Total Capacity: 128GB
8GB Allocated to real-time data redundancy and error correction

Formatted Capacity

112GiB

Drive Format

Unformatted (Instructions on formatting here)

Controller

SandForce 2281 Series Processor with 7% over-provisioning

NAND Flash Components

Tier 1 Major Synchronous Multi-Level Cell (MLC) NAND Flash

S.M.A.R.T. Attributes

Standard attributes supported

Native Command Queuing (NCQ)

Up to 32 simultaneous commands

RAID Support

Form Factor

2.5-inch 7mm

Drive Interface

SATA 6.0 Gb/s

Random 4K Read

Up to 60,000 IOPS

Random 4K Write

Up to 60,000 IOPS

Sustained Read (3Gb/s)

Up to 284 MB/s

Sustained Write (3Gb/s)

Up to 266 MB/s

Sustained Read (6Gb/s)

Up to 559 MB/s

Sustained Write (6Gb/s)

Up to 527 MB/s

Read Latency (Max)

100 µs

Write Latency (Max)

100 µs

Read Incompressible Data Rate (up to)

479 MB/s

Write Incompressible Data Rate (up to)

282 MB/s

Nonrecoverable Read Errors

1 per 10¹⁶ bits read

TRIM Support

OS Dependent

Error Correction

Built-in ECC

Security

Chip Based Data Encryption: 128-bit AES-compliant

Read Mode (Max)

Up to 3 Watts

Write Mode (Max)

Up to 4.5 Watts

Idle Mode (Max)

Up to 1 Watts

Dimensions

Height: 0.7 cm (0.3 in)
Length: 10.0 cm (3.9 in)
Width: 7.0 cm (2.8 in)

Weight

77.0 g (0.17 lbs)

RoHS Compliant

Ambient Temperature

Operating: 32°F to 158°F (0°C to 70°C)
Non-Operating: -40°F to 185°F (-40°C to 85°C)

Altitude

Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft)
Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)

Idle (Typical)

0.0 bels

Seek (Typical)

0.0 bels

1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less). The actual total capacity will depend on your own defined file settings/preferences.
In terms of standard gigabytes, 1GiB ˜ 1.074GB and refers to the actual formatted capacity of shown under Mac OS 10.5 or earlier and Microsoft Windows OS.
Specific application environments such as temperature and duty cycle will affect the overall reliability.
Temperature reporting is currently an unsupported feature because due to the operating characteristics of SSDs, it is highly unlikely one would ever exceed an OWC Mercury SSD's stated operating temperature ceiling of 158F/70C. However, we are looking into supporting this feature in the future via a firmware update. Firmware updates can be found here: http://eshop.macsales.com/tech_center/OWC/SSD.

Compatibility & Installation Videos

MacBook Pro

MacBook Pro (13-inch, Mid 2012)

Mid 2012

Model ID: MacBookPro9,2

2.5GHz Core i5 & 2.9GHz Core i7
